Brilnurse 4-Output TENS Muscle Stimulator User Manual

Sarrera

Thank you for choosing the Brilnurse 4-Output TENS Muscle Stimulator. This device is designed to provide temporary relief of pain associated with sore and aching muscles due to strain from exercise or normal household and work activities. It uses Transcutaneous Electrical Nerve Stimulation (TENS) technology to deliver gentle electrical pulses through electrodes placed on the skin, stimulating nerves and muscles.

Please read this manual thoroughly before using the device to ensure safe and effective operation. Keep this manual for future reference.

Segurtasun informazio garrantzitsua

OHARRA: Do not use this device if you have a pacemaker, implanted defibrillator, or other implanted metallic or electronic device. Consult your physician before use if you have any medical conditions, including but not limited to:

• Haurdunaldia
• Bihotzeko gaixotasuna
• Epilepsia
• Minbizia
• Azken kirurgia
• Skin conditions or open wounds in the treatment area

Neurriak:

• Do not place electrode pads on the head, face, throat, or across the chest.
• Do not use while driving, operating machinery, or during any activity where involuntary muscle contractions could put the user at undue risk.
• Mantendu haurren eskura.
• Ez erabili bainuan edo dutxan.
• Discontinue use if you experience any adverse reactions such as skin irritation, redness, or discomfort.
• Only use accessories provided or recommended by Brilnurse.

Produktua amaituview

Ezaugarri nagusiak

• 4 kanal independente: Allows for simultaneous treatment of up to 8 electrode pads with different modes and intensities.
• 24 masaje modu: A variety of pre-programmed modes for diverse pain relief and muscle stimulation needs.
• 20 intentsitate maila: Adjustable intensity to customize your therapy experience.
• Litiozko bateria kargagarria: Gehienez 20 orduko erabilera etengabea ematen du karga bakarrean.
• Tenporizadore erregulagarria: Session duration can be set from 10 to 60 minutes.
• Memoria Funtzioa: Remembers the last used mode and intensity settings.

Paketearen edukia

Image: Contents of the Brilnurse TENS Muscle Stimulator package, including the device, electrode pads, lead wires, USB cable, pad holder, and storage bag.

• 1 x Brilnurse 4-Output TENS Device
• 4 x Hari-kableak
• 16 x Electrode Pads (8 Palm pads, 4 Large Rectangular pads, 4 Oval pads)
• 1 x USB kablea
• 1 x Pad Holder
• 1 x Biltegiratzeko poltsa
• 1 x Erabiltzailearen eskuliburua

Gailuaren osagaiak eta kontrolak

Irudia: Aurrealdea eta goialdea view of the Brilnurse TENS unit with labels indicating Output A1/A2, Output B1/B2, Time indicator, Battery indicator, LCD screen, Mode indicator, A/B Intensity indicator, Lock indicator, A/B Intensity adjustment buttons, Mode selector, Time adjustment, USB port, and On/Off switch.

• LCD pantaila: Displays mode, intensity, time, and battery status.
• Output Ports (A1, A2, B1, B2): Connect lead wires for electrode pads.
• Piztu/Itzali etengailua: Gailua piztu edo itzaltzen du.
• Modu botoia (M): Cycles through the 24 available massage modes.
• Time Button (T): Adjusts the treatment duration (10-60 minutes).
• Intensity Buttons (+/-): Adjusts the intensity level for channels A and B independently.
• Blokeatzeko botoia: Locks the screen to prevent accidental changes.
• USB kargatzeko ataka: Barneko bateria berriro kargatzeko.

Konfigurazioa

1. Gailua kargatzea

1. Ziurtatu gailua itzalita dagoela.
2. Connect the provided USB cable to the charging port on the device.
3. Plug the other end of the USB cable into a USB wall charger (not included), power bank, or computer USB port.
4. The battery indicator on the LCD screen will show charging status. A full charge typically takes a few hours and provides up to 20 hours of use.

2. Connecting Lead Wires and Electrode Pads

1. Insert the pin connectors of the lead wires into the electrode pads. Ensure a secure connection.
2. Plug the lead wire connectors into the output ports (A1, A2, B1, B2) on the top of the TENS unit. Each lead wire has two pin connectors for two pads.
3. For optimal adhesion and longevity of the pads, clean the skin area where pads will be applied with soap and water, then dry thoroughly. Avoid applying pads to broken or irritated skin.

Funtzionamendu-argibideak

1. Elektrodo-konpresak jartzea

Carefully peel the electrode pads from their protective film. Apply the sticky side of the pads firmly to the clean, dry skin area requiring treatment. Ensure the pads are flat against the skin and not overlapping.

Image: Visual guide for common TENS pad placement locations on the body, including back, shoulders, arms, and legs, for pain relief.

For best results, place pads on either side of the pain area, or on specific muscle groups. Refer to the included pad placement guide for detailed recommendations.

Image: A woman demonstrating the use of the Brilnurse TENS unit with electrode pads applied to her shoulders and upper back, illustrating the independent channel functionality.

2. Piztea eta modua hautatzea

1. Slide the On/Off switch to the "On" position. The LCD screen will illuminate.
2. Sakatu M (Mode) button to cycle through the 24 available massage modes. The selected mode will be displayed on the screen.

3. Intentsitatea doitzea

The Brilnurse TENS unit features 4 independent channels (A1, A2, B1, B2) grouped into two adjustable pairs (A and B). This allows you to set different intensity levels for different body areas simultaneously.

• Erabili A +/- buttons to adjust the intensity for channels A1 and A2.
• Erabili B +/- buttons to adjust the intensity for channels B1 and B2.
• Start with the lowest intensity and gradually increase until you feel a comfortable, gentle pulsing sensation. Avoid increasing intentsitatea maila mingarri bateraino.

Image: The Brilnurse TENS unit display illustrating the 20 intensity levels, categorized by their general effects such as Muscle Activation, Fascia Relaxation, Lactic Acid reduction, Deep Massage, and Professional Mode.

4. Tenporizadorea ezartzea

1. Sakatu T (Time) button to adjust the treatment duration.
2. The timer can be set from 10 to 60 minutes in 10-minute increments.
3. The device will automatically shut off once the timer counts down to zero.

5. Locking the Screen

To prevent accidental changes to settings during a session, press and hold the 'M' button for a few seconds to lock the screen. Repeat to unlock.

6. Ending a Session

1. When the session is complete, or if you wish to stop early, turn off the device using the On/Off switch.
2. Gently peel the electrode pads from your skin. Do not pull on the wires.

Mantentzea

Gailua garbitzea

Garbitu gailua leun batekin, damp oihal. Ez erabili garbitzaile urratzailerik eta ez sartu gailua uretan.

Caring for Electrode Pads

• After each use, place the electrode pads back onto their protective film or the included pad holder.
• If pads lose their stickiness, gently dab the adhesive side with a few drops of water to reactivate. Allow to air dry slightly before reapplication.
• Replace pads when they no longer adhere well to the skin, as poor adhesion can reduce effectiveness and cause discomfort.

Biltegiratzea

Store the device and accessories in the provided storage bag in a cool, dry place, away from direct sunlight and extreme temperatures. Ensure the device is fully charged before long-term storage.

Arazoak konpontzea

Zehaztapenak

Bermea eta Laguntza

The Brilnurse TENS Muscle Stimulator comes with a standard one-year warranty. You may be eligible for an extended warranty of an additional two years upon product registration with Brilnurse.

For any questions, concerns, or support needs, please do not hesitate to contact Brilnurse customer service. We aim to respond to all inquiries within 24 hours.

Please refer to the contact information provided on the product packaging or the official Brilnurse webwebgunea laguntza-xehetasun eguneratuenak lortzeko.
