Tyler Portable CD Player Boombox

Sarrera

This manual provides detailed instructions for the operation and maintenance of your Tyler Portable CD Player Boombox, Model TAU107. Please read this manual thoroughly before using the device to ensure proper function and longevity.

Image: The Tyler Portable CD Player Boombox, Model TAU107, in white with black accents. A CD is shown partially inserted into the top-loading tray, highlighting its primary function. The device features a handle for portability and visible control buttons.

Kutxan dagoena

• Tyler Portable CD Player Boombox (Model TAU107)
• AC korronte kablea
• Erabiltzailearen eskuliburua

Produktua amaituview

Familiarize yourself with the various components and controls of your boombox.

Image: A detailed diagram of the Tyler TAU107 Boombox, highlighting its various components and controls. Labels point to the handle, CD slot, control panel, LCD display, USB-A port, dual speakers, AC plug input, battery slot, FM tuning selector, headphones jack, AUX jack, and volume wheel.

Kontrol panelaren funtzioak:

• POWER botoia: Unitatea pizten edo itzaltzen du.
• FUNCTION Selector: Switches between CD, FM, Bluetooth, USB, and AUX modes.
• PLAY/PAUSE botoia: Erreprodukzioa hasten edo eten egiten du.
• STOP botoia: Erreprodukzioa geldiarazten du.
• SALTATU/BILATU botoiak (◀◀ / ▶▶): Pistak saltatzen ditu edo pista baten barruan bilatzen du.
• PROGRAMAZIOA botoia: Used for programming CD playback order.
• EQ botoia: Selects equalizer presets (FLAT, CLASSICAL, JAZZ, ROCK, POP).
• VOLUME Wheel: Audio irteera-maila doitzen du.
• LCD pantaila: Shows current mode, track number, and other information.

Konfigurazioa

Boombox-ari indarra ematea:

The TAU107 can be powered by AC current or batteries for portable use.

Image: A split image illustrating power options. The top shows the boombox plugged into a wall outlet for AC operation. The bottom shows the boombox outdoors on a picnic blanket, indicating its portability with DC battery power.

AC funtzionamendua:

1. Ziurtatu unitatea itzalita dagoela.
2. Connect the supplied AC power cord to the AC input jack on the back of the boombox.
3. Entxufatu korronte alternoko kablearen beste muturra hormako entxufe estandar batera (100-240 VAC, 50/60 Hz).

DC (Battery) Operation:

1. Ziurtatu unitatea itzalita dagoela.
2. Ireki unitatearen behealdean dagoen bateriaren konpartimentuaren estalkia.
3. Insert 4 x R14/Size C dry batteries (not included), ensuring correct polarity (+/-). Alkaline batteries are recommended for best performance.
4. Itxi bateriaren konpartimenduaren estalkia ondo.

Funtzionamendu-argibideak

CD erreprodukzioa:

Image: A hand is shown carefully placing a CD into the top-loading compartment of the boombox. Below this, a graphic displays FM radio frequencies ranging from 87.5 MHz to 108 MHz, indicating the device's radio capabilities.

1. Lift the CD compartment door.
2. Garrantzitsua: Remove any protective cardboard from the CD lens before inserting a CD.
3. Jarri CD bat (CD, CD-R/RW, HDCD, WMA, MP3 CD edo audio-liburuen CD) ardatzean, etiketa gora begira duela.
4. Gently close the CD compartment door.
5. Sakatu FUNTZIOA selector to choose 'CD' mode.
6. Sakatu JOLASTU/PAUSTU botoia erreproduzitzen hasteko.
7. Erabili SALTU / BILATU botoiak pisten artean nabigatzeko.
8. Sakatu GELDITU botoia erreprodukzioa amaitzeko.

CD Pistak programatzea:

1. In CD mode, with the CD stopped, press the PROGRAMA botoia.
2. The display will show 'P01'. Use the SALTU / BILATU buttons to select the desired first track.
3. Sakatu PROGRAMA again to confirm and move to 'P02'.
4. Errepikatu gehienez 20 pista programatzeko.
5. Sakatu JOLASTU/PAUSTU programatutako erreprodukzioa hasteko.

FM irratia:

1. Sakatu FUNTZIOA selector to choose 'FM' mode.
2. Biratu FM TUNING SELECTOR on the side of the unit to manually tune to a desired station.
3. To auto-scan and save stations: Press and hold the JOLASTU/PAUSTU botoia. Irratiak eskuragarri dauden 20 irrati-kate eskaneatu eta gordeko ditu.
4. Erabili SALTU / BILATU botoiak gordetako geltokietan zehar nabigatzeko.

Bluetooth konexioa:

Image: The Tyler Boombox is positioned next to a smartphone, which shows its Bluetooth settings screen. This setup illustrates the boombox's capability for wireless music streaming via Bluetooth V5.0.

1. Sakatu FUNTZIOA selector to choose 'BT' (Bluetooth) mode. The unit will enter pairing mode, indicated by a flashing Bluetooth icon on the LCD display.
2. Bluetooth gaitutako gailuan (adibidez, telefono adimenduna, tableta), gaitu Bluetooth eta bilatu eskuragarri dauden gailuak.
3. Select 'TAU107' from the list of devices.
4. Once paired, the Bluetooth icon on the boombox's display will stop flashing.
5. You can now play audio from your device through the boombox.

USB erreprodukzioa:

Image: A USB flash drive is clearly shown inserted into the USB-A port located on the front panel of the Tyler Boombox, demonstrating its capability to play MP3 and WMA files zuzenean USB biltegiratze gailu batetik.

1. Sartu MP3 edo WMA audioa duen USB flash drive bat files USB-A atakan.
2. Sakatu FUNTZIOA selector to choose 'USB' mode.
3. Erreprodukzioa automatikoki hasiko da. Erabili JOLASTU/PAUSTU eta SALTU / BILATU erreprodukzioa kontrolatzeko botoiak.

Sarrera osagarria:

Image: A split image. The top shows the Tyler Boombox connected to an external speaker via an Aux-in cable, demonstrating its auxiliary input capability. The bottom shows a person wearing headphones, indicating the use of the stereo headphone jack for private listening.

1. Connect an external audio device (e.g., smartphone, MP3 player) to the 3.5mm AUX input jack using an audio cable (not included).
2. Sakatu FUNTZIOA selector to choose 'AUX' mode.
3. Control playback directly from your connected external device.

Aurikularrak Jack:

1. Plug 3.5mm stereo headphones into the headphone jack on the side of the unit.
2. Audio will automatically switch from the built-in speakers to the headphones.
3. Doitu bolumena BOLUMENA gurpila.

Ekualizatzaile (EQ) moduak:

Sakatu EQ button repeatedly to cycle through the available sound presets:

• LAUA: Default, unenhanced sound.
• CLASSICAL: Musika klasikorako optimizatua.
• JAZZ: Optimized for jazz music.
• ROCK: Optimized for rock music.
• POP: Optimized for pop music.

Mantentzea

Unitatea garbitzea:

• Deskonektatu beti unitatea elikadura-iturritik garbitu aurretik.
• Erabili zapi leun eta lehor bat kanpoko gainazalak garbitzeko.
• Ez erabili garbitzaile urratzailerik, argizaririk edo disolbatzailerik.

CD Lenteen Zaintza:

• Avoid touching the CD lens inside the compartment.
• If the lens becomes dirty, use a specialized CD lens cleaner disc (not included) to clean it.

Bateria ordezkatzea:

• When the unit's performance degrades during battery operation, replace all 4 C-size batteries with new ones.
• Ziurtatu polaritate zuzena bateria berriak sartzerakoan.
• Kendu bateriak unitatea denbora luzez erabiliko ez bada, isuriak saihesteko.

Arazoak konpontzea

Zehaztapenak

Bermea eta Laguntza

Bermearen informazioa:

Your Tyler Portable CD Player Boombox, Model TAU107, is backed by a 5 urteko bermeaBerme honek materialen eta fabrikazioaren akatsak estaltzen ditu erabilera normalaren pean. Gorde erosketaren egiaztagiria bermearen erreklamazioak egiteko.

Bezeroarentzako laguntza:

For any questions, technical assistance, or warranty service, please contact Tyler customer support. Refer to the contact information provided on the Tyler official webgunea edo zure erosketa-dokumentazioa.
