COSTWAY 10713DK-CYBC
COSTWAY Big and Tall Massage Office Chair User Manual
Model: 10713DK-CYBC
1. Sarrera
Thank you for choosing the COSTWAY Big and Tall Massage Office Chair. This chair is designed to provide comfort and support with its ergonomic features, including a 6-point massage system, retractable footrest, reclining backrest, and adjustable swivel seat. Please read this manual thoroughly before assembly and use to ensure proper operation and longevity of your product.

Image 1.1: The COSTWAY Big and Tall Massage Office Chair, designed for comfort and support, shown with a user.
2. Segurtasun informazioa
- Ziurtatu osagai guztiak daudela eta kalterik gabe muntatu aurretik.
- Jarraitu muntaketa-argibideak arretaz. Ez estutu gehiegi torlojuak.
- Ez jarri aulkian.
- Ez erabili aulkia piezaren bat falta bada edo hondatuta badago.
- Mantendu haurrak mugitzen diren piezen eskura doikuntza bitartean.
- Maximum weight capacity for this chair is 400 lbs (181.5 kg). Do not exceed this limit.
- Erabili aulkia gainazal mailakatu batean.
3. Paketearen edukia
Egiaztatu behean zerrendatutako elementu guztiak zure paketean sartuta daudela:
- 1 x Bulegoko masaje-aulkia (osagai desmuntatuak)
- 1 x Erabiltzailearen Gida
4. Konfigurazioa eta Muntaketa
Assembly of the COSTWAY Massage Office Chair requires careful attention to detail. Please refer to the included user guide for step-by-step visual instructions. Ensure all parts are securely fastened before use.

Image 4.1: Key components for chair assembly, including the heavy-duty gas rod, 5-claw metal base, and universal wheels.
Batzar Nagusiaren urratsak:
- Attach the universal wheels to the 5-claw metal base.
- Insert the heavy-duty gas rod into the center of the base.
- Assemble the seat and backrest components according to the detailed diagrams in the separate user guide.
- Attach the assembled seat to the gas rod.
- Ziurtatu konexio guztiak sendoak eta egonkorrak direla.
5. Funtzionamendu-argibideak
5.1 Masaje funtzioa
The chair features a 6-point vibration massage system for the shoulders, back, and hips. It offers 3 intensity levels and 5 preset modes, controlled by a wired remote. The remote can be stored in the side pocket when not in use.

5.1.1. irudia: Amaituview of the massage chair with highlighted massage points and the remote control.

Image 5.1.2: Illustration of the 6 vibration massage points and remote control features.
5.2 Reclining Backrest
The backrest can be reclined between 98° and 145° to suit various activities such as working, gaming, reading, or sleeping. Use the backrest locking lever located on the side of the chair to adjust and secure the desired angle.

Image 5.2.1: Seating flexibility features, including reclining backrest and height adjustment.
5.3 Altuera doitzea
Adjust the seat height from 19 inches to 22 inches (a 3-inch range) to match your desk and personal preference. Use the height adjustment lever located beneath the seat to raise or lower the chair.
5.4 Retractable Footrest
For added comfort, especially when reclining, extend the retractable footrest. Pull the footrest out from under the seat until it locks into position. Push it back in when not needed.

Image 5.4.1: A user demonstrating the extended retractable footrest for relaxation.

5.4.2 irudia: Xehetasun zehatza view of ergonomic features including the headrest, armrests, and retractable footrest.
5.5 Biraketa funtzioa
The chair features a 360° swivel seat, allowing for easy movement and access within your workspace without needing to reposition the entire chair.
6. Mantentzea
To ensure the longevity and appearance of your COSTWAY Massage Office Chair, follow these maintenance guidelines:
- PU larrua garbitzea: The chair's PU leather is waterproof and easy to clean. Wipe spills immediately with a soft, damp oihal. Garbiketa orokorrerako, erabili xaboi leun baten disoluzioa eta oihal leun bat, eta gero lehortu. Saihestu produktu kimiko gogorrak edo garbitzaile urratzaileak.
- Caster Wheels: Periodically check the universal wheels for hair or debris that may hinder smooth movement. Clean as necessary.
- Loturak: Occasionally check all screws and bolts to ensure they remain tight. Retighten if loose.

Image 6.1: Details of the chair's padded design, highlighting the waterproof PU leather and high-density sponge for comfort and easy maintenance.
7. Arazoak
Zure aulkiarekin arazorik baduzu, jo ezazu arazoak konpontzeko aholku ohiko hauetara:
- Aulkia ez da altuera doitzen: Ensure the height adjustment lever is fully engaged and the gas rod is properly seated. Check for any obstructions.
- Masaje funtzioa ez dabil: Verify the power connection to the remote control and ensure the remote is properly plugged into the chair. Check if the power outlet is functional.
- Aulkia dardarka: Check all assembly screws and bolts, especially those connecting the base and seat, and tighten them securely. Ensure the chair is on a flat, even surface.
- Gurpilak ez dira ondo biratzen: Inspect the wheels for any trapped debris, hair, or lint and remove them.
Irtenbide hauek saiatu ondoren arazoak konpontzen ez badira, jarri harremanetan bezeroarentzako arreta-zerbitzuarekin.
8. Zehaztapenak
Detailed specifications for the COSTWAY Big and Tall Massage Office Chair:

8.1 irudia: Aulkiaren neurri zehatzak.
| Ezaugarri | Xehetasuna |
|---|---|
| Marka | KOSTWAY |
| Ereduaren izena | Massage Office Desk Chair |
| Modelo zenbakia | 10713DK-CYBC |
| Kolorea | Beltza |
| Neurri orokorrak (L x W x H) | 27" x 26.5" x 45"-48" (69 x 67 x 114-121.5 cm) |
| Eserlekuaren neurriak (Z x S x A) | 21" x 20.5" x 19"-22" (54 x 52 x 49-56.5 cm) |
| Altuera doitzeko tartea | 3" (7.5 cm) |
| Bizkarraldearen neurriak (Z x A) | 19" x 27.5" (49 x 70 cm) |
| Besaulkiaren altuera | 27"-30" (68-75.5 cm) |
| Footrest Dimensions (L x W x H) | 36 x 20 x 6 cm (14" x 8" x 2.5") |
| Footrest Retractable Distance | 14" (36 cm) |
| Reclining Angle of Backrest | 98°-145° |
| Gehienezko Karga Edukiera | 400 lb (181.5 kg) |
| Pisu garbia | 44 lb (20 kg) |
| Materiala | PU, PVC, Sponge, Plywood, Electroplated Metal, Nylon |
| Ezaugarri bereziak | Adjustable Height, Ergonomic, Foot Rest, Head Support, Reclining, 6-Point Massage |
9. Bermea eta Laguntza
For warranty information or technical support, please refer to the specific warranty card included with your product or contact COSTWAY customer service directly. Ensure you have your model number (10713DK-CYBC) and purchase details available when contacting support.
