Sarrera
This manual provides essential information for the safe and efficient installation, operation, and maintenance of your Atlantic Nanto 831236 30L Electric Water Heater. Please read these instructions carefully before installation and use, and keep them for future reference. Proper installation and adherence to these guidelines will ensure optimal performance and longevity of your appliance.
Segurtasun Informazioa
Bete beti segurtasun neurri hauek sute, deskarga elektriko, lesio edo tresnari kalteak eragiteko arriskua murrizteko.
- Instalazioa profesional kualifikatu batek egin behar du, tokiko araudi eta estandarren arabera.
- Ensure the electrical supply matches the specifications of the water heater (220-240V~, 50-60Hz).
- Ez jarri ur-berogailua martxan hondatuta edo gaizki funtzionatzen badu.
- Never block ventilation openings.
- Deskonektatu elektrizitatea edozein mantentze edo konponketa egin aurretik.
- Tresna hau ez da gaitasun fisiko, sentsorial edo mental murriztua duten pertsonek (haurrak barne) edo esperientzia eta ezagutza falta duten pertsonek erabiltzeko, baldin eta haien segurtasunaz arduratzen den pertsona batek aparatua erabiltzeari buruzko gainbegiratu edo jarraibiderik eman ez badu. .
Konfigurazioa eta Instalazioa
The Atlantic Nanto 831236 is designed for wall-mounted, above-sink installation. Ensure the mounting surface is strong enough to support the full weight of the water heater when filled with water (approximately 45 kg).
Despaketatzea
Carefully remove the water heater from its packaging. Inspect for any signs of damage. Keep packaging materials away from children.
Image: Packaging of the Atlantic Nanto 30L electric water heater, displaying product details and branding.
Image: Packaging of the Atlantic Nanto 30L electric water heater, illustrating its dimensions for installation planning.
Muntaketa
- Select a suitable wall location above the sink, ensuring sufficient clearance for maintenance and operation.
- Mark the drilling points for the mounting brackets on the wall. Refer to the rear view of the unit for bracket positions.
- Drill holes and insert appropriate wall anchors. Secure the mounting brackets firmly to the wall.
- Carefully lift the water heater and hang it onto the secured wall brackets. Ensure it is level and stable.
Irudia: Atzealdea view of the Atlantic Nanto 30L electric water heater, highlighting the mounting points and electrical connection area.
Iturgintza-konexioak
- Connect the cold water inlet (usually marked blue) to the main cold water supply.
- Connect the hot water outlet (usually marked red) to the hot water tap.
- Install a pressure relief valve on the cold water inlet, as required by local codes.
- Ziurtatu konexio guztiak iragazgaitzak direla.
Konexio elektrikoa
- Ensure the power supply is disconnected before making electrical connections.
- Connect the water heater to a dedicated, properly grounded electrical circuit.
- The appliance operates at 220-240V~, 50-60Hz, with a power rating of 1500W.
- Verify all electrical connections are secure and comply with local electrical codes.
Image: Product label of the Atlantic Nanto 831236 water heater, detailing its electrical specifications and IP24 rating.
Funtzionamendu-argibideak
Once installed and filled with water, your Atlantic Nanto water heater is ready for operation.
Depositua betetzea
- Before switching on the power, open a hot water tap in your sink to allow air to escape from the tank.
- Turn on the cold water supply to the water heater.
- Wait until water flows steadily from the hot water tap, indicating the tank is full. Close the hot water tap.
Powering On and Temperature Adjustment
- Connect the water heater to the electrical supply. The power indicator light (if present) will illuminate.
- Use the temperature control knob located on the front of the unit to set your desired water temperature. Turning the knob clockwise typically increases the temperature.
- The water heater will begin heating the water. Heating time will vary depending on the initial water temperature and the selected setting.
Irudia: Aurrealdea view of the Atlantic Nanto 30L electric water heater, showing the temperature control knob for user adjustment.
Energia aurrezteko aholkuak
- Set the temperature to the lowest comfortable level to save energy.
- Consider insulating hot water pipes to reduce heat loss.
- The appliance has an energy efficiency class C.
Mantentzea
Regular maintenance ensures the efficient and safe operation of your water heater.
Urteko Ikuskapena
- It is recommended to have a qualified technician inspect the water heater annually.
- This inspection should include checking the heating element, anode rod (if applicable), and pressure relief valve.
Depositua drainatzea
If the water heater will be out of use for an extended period or if there is a risk of freezing, the tank should be drained.
- Deskonektatu ur-berogailuaren hornidura.
- Itxi ur hotzaren sarrerako balbula.
- Open a hot water tap to release pressure.
- Connect a hose to the drain valve (if present) or disconnect the cold water inlet pipe to drain the tank.
Garbiketa
Garbitu ur-berogailuaren kanpoaldea oihal leun eta lehor batekinamp oihal. Ez erabili garbitzaile edo disolbatzaile urratzailerik.
Arazoak konpontzea
Bezeroarentzako arreta-zerbitzuarekin harremanetan jarri aurretik, kontsultatu honako arazo eta irtenbide ohikoenak.
| Arazoa | Kausa posiblea | Irtenbidea |
|---|---|---|
| Ur berorik ez | Ez dago elikadura hornidurarik Termostatoa baxuegi ezarrita Berokuntza-elementuaren matxura | Egiaztatu zirkuitu-hauslea/fusiblea Doitu termostatoaren ezarpena Jarri harremanetan teknikari kualifikatu batekin |
| Ur beroa nahikoa ez | Termostatoa baxuegi ezarrita Excessive hot water usage Sedimentuen metaketa | Handitu termostatoaren ezarpena Allow time for reheating Contact a qualified technician for descaling |
| Ur-ihesak | Iturgintzako konexio solteak Pressure relief valve discharge Tank corrosion | Konexioak estutu This is normal if pressure is too high; check system pressure Jarri harremanetan teknikari kualifikatu batekin |
| Ezohiko zaratak | Sedimentuen metaketa Osagai solteak | Contact a qualified technician for descaling Jarri harremanetan teknikari kualifikatu batekin |
Zehaztapenak
Detailed technical specifications for the Atlantic Nanto 831236 Electric Water Heater.
Image: Internal diagram of an electric water heater, illustrating the heating element, insulation, and water tank components.
- Marka: Atlantikoa
- Modelo zenbakia: 831236
- Edukiera: 30 litro
- Kolorea: Zuria
- Energia-eraginkortasun klasea: C
- Muntatze mota: Wall mount (Above sink)
- Potentzia: 1500 W
- liburukiatage: 220-240 V ~
- Maiztasuna: 50-60 Hz
- IP balorazioa: IP24
- Neurriak (gutxi gorabehera): 44 cm (Zabalera) x 39 cm (Sakonera) x 46 cm (Altuera)
Bermea eta laguntza
For warranty information, please refer to the warranty card included with your product or contact Atlantic customer service. Keep your proof of purchase for warranty claims.
For technical support or service, please contact your local Atlantic dealer or authorized service center. You can find contact information on the official Atlantic webgunea edo zure dendariaren bidez.
