Chairman Business Chair Instruction Manual

1. Produktua amaitu daview

This executive office chair is designed to provide comprehensive support and comfort during extended periods of use. It features an ergonomic high backrest, premium microfiber leather upholstery, and high-density latex and sponge filling for a plush seating experience.

Key features include a wide seat cushion, thickly padded armrests, and a design focused on improving work efficiency and comfort.

1.1. irudia: Aurrealdea view of the Chairman Business Chair. This image displays the overall design and structure of the chair, highlighting its high back, padded armrests, and five-star base with casters.

1.2. irudia: Illustration of ergonomic support points. This image highlights the partitioned support for the shoulders, neck, waist, and buttocks, designed to conform to the human body for stable and comfortable seating.

1.3. irudia: Gertutik view of the chair's materials. This image shows the high-quality microfiber leather, emphasizing its waterproof and wear-resistant properties, along with a cross-section illustrating the 11cm thick latex and sponge filling for enhanced comfort.

2. Konfigurazioa eta Muntaketa

Your Chairman Business Chair comes with all necessary hardware and tools for assembly. Please follow these general steps. Refer to the detailed assembly diagram included in your product packaging for specific instructions.

1. Deskonprimitu osagaiak: Carefully remove all parts from the packaging and lay them out on a clean, flat surface. Verify all components are present against the parts list in your manual.
2. Gurpilak oinarrira lotu: Sartu bost gurpilak bost izardun oinarriaren hanka bakoitzaren muturretan dauden zuloetan. Sakatu ondo klik egin arte.
3. Txertatu gas-igogailua: Jarri gas-igogailuaren zilindroa bost izarretako oinarriaren erdiko zuloan. Ziurtatu ondo finkatuta dagoela.
4. Muntatu eserlekuaren mekanismoa: Attach the seat mechanism to the underside of the seat cushion using the provided screws. Ensure the front of the mechanism faces the front of the seat.
5. Erantsi beso-euskarriak: Secure the armrests to the seat cushion using the designated screws. Do not overtighten initially.
6. Konektatu bizkarraldea eserlekuari: Attach the backrest to the seat assembly, typically by aligning brackets and securing with screws.
7. Jarri eserlekuaren multzoa gas-igogailuan: Jarri kontu handiz muntatutako eserlekua eta bizkarraldea gas-igogailuaren zilindroaren gainean, erdian eta egonkor dagoela ziurtatuz.
8. Azken estutzea: Pieza guztiak muntatuta daudenean, torloju guztiak ondo estutu.

Assembly typically takes 15-20 minutes.

3. Funtzionamendu-argibideak

The Chairman Business Chair offers several adjustment features to customize your seating experience for optimal comfort and support.

• Eserlekuaren altuera doitzea: To raise the seat, lift the lever located under the right side of the seat while taking your weight off the chair. To lower the seat, lift the lever while seated. The seat height can be adjusted within a 10cm range.
• Etzanda angeluaren doikuntza: The backrest can be tilted between 90° and 165°. Use the recline lever (typically on the left side) to unlock the recline function. Lean back to your desired angle and push the lever down to lock it in place.

3.1. irudia: Illustration of the 90-135 degree adjustable recline. This image demonstrates the flexible seating options provided by the chair's adjustable backrest angle.

• Oin-euskarriaren luzapena: To use the integrated footrest, pull it out from under the seat. Extend it to your desired length and position your legs for relaxation. Push it back in when not in use.
• Biratu funtzioa: The chair is equipped with a 360° swivel mechanism, allowing for easy rotation without moving the base. The rubber wheels ensure smooth and quiet movement.
• Buru-euskarriaren doikuntza: The headrest is two-way adjustable, allowing for 4cm lift and 45° rotation to provide optimal support for your head and neck.

3.2. irudia: Details of the lifting and rotating headrest. This image shows the two-way adjustable headrest, illustrating its 4cm liftable and 45° rotatable features for effective head and neck support.

4. Mantentzea

Proper care and maintenance will extend the life and appearance of your Chairman Business Chair.

• Cleaning Microfiber Leather: The premium microfiber leather is wear-resistant and stain-resistant. For general cleaning, wipe gently with a soft, damp cloth. For tougher stains, use a mild soap solution and wipe immediately with a clean, dry cloth. Avoid harsh chemicals or abrasive cleaners.
• Gurpilen mantentze-lanak: Periodically check the casters for hair or debris that may hinder smooth movement. Clean as needed.
• Hardwarearen egiaztapena: Hilabete batzuk igaro ondoren, egiaztatu torloju eta azkoin guztiak ondo estutu direla ziurtatzeko. Beharrezkoa bada, berriro estutu egonkortasuna eta segurtasuna mantentzeko.

5. Arazoak

Zure aulkiarekin arazorik baduzu, jo ezazu honako ohiko irtenbide hauetara:

• Aulkiaren kirrinka: Check all bolts and screws for tightness. Apply a small amount of silicone-based lubricant to moving parts if squeaking persists.
• Altuera doitzeko zailtasuna: Ziurtatu gas igogailuaren palanka guztiz sartuta dagoela. Arazoak jarraitzen badu, baliteke gas igogailuaren zilindroa ordezkatu behar izatea.
• Aulkiaren dardarak: Verify that all connections are secure and that the chair is assembled on a flat, even surface.
• Gurpilak ez dira leunki biratzen: Inspect casters for debris (hair, lint) and clean them. Ensure they are properly inserted into the base.

6. Zehaztapenak

Detailed specifications for the Chairman Business Chair Model 66233797:

6.1. irudia: Dimensional diagram of the Chairman Business Chair. This image provides key measurements including overall height (108-118cm), seat height (46-56cm), seat width (46cm), seat depth (50cm), and overall width (66cm).

7. Bermearen informazioa

This product is covered by a manufacturer's warranty against defects in materials and workmanship. Please refer to the warranty card included with your purchase for specific terms, conditions, and duration. Keep your proof of purchase for warranty claims.

8. Bezeroarentzako arreta

For any questions, assistance with assembly, or troubleshooting not covered in this manual, please contact the manufacturer's customer support. Contact details can typically be found on the product packaging or the manufacturer's official webgunea.
