wendeekun 4G LTE Modem Dongle User Manual

Sarrera

This user manual provides comprehensive instructions for the wendeekun 4G LTE Modem Dongle (Model: B08Z7YRVGS). This device is designed to provide high-speed 4G LTE internet access by simply inserting a SIM card, allowing you to create and share network hotspots. It supports up to 10 associated users and offers a convenient plug-and-play experience across various operating systems.

Produktua amaituview

The wendeekun 4G LTE Modem Dongle is a compact and portable device that provides wireless internet connectivity. It features a USB interface for power and data transfer, a SIM card slot, and an LED status indicator.

1. irudia: Aurrealdea view of the wendeekun 4G LTE Modem Dongle, showing the 4G LTE WiFi Modem branding.

2. irudia: The modem dongle with its USB connector exposed, ready for connection to a computer or power source.

3. irudia: Atzekoa view of the modem dongle, displaying technical specifications such as DL: 150Mbps UL: 50Mbps and WiFi Cat4.

Ezaugarri nagusiak:

• Erabiltzeko erraza: USB interface for plug-and-play functionality.
• High-speed Connectivity: Supports up to 150Mbps downlink and 50Mbps uplink (4G LTE CAT4).
• SIM txartelaren zirrikitua: Enables 4G internet access and hotspot sharing without broadband.
• LED egoeraren adierazlea: Gailuaren egoerari buruzko iritzi bisuala ematen du.
• Memoria Txartelaren Hedapena: Supports expansion with a small memory card up to 32GB (not included).
• Bateragarritasun zabala: Compatible with Windows, OS X, Android, and Linux operating systems.
• Diseinu eramangarria: Small and convenient for on-the-go use.

Paketearen edukia:

• 1 x Modem Dongle
• 1 x Erabiltzailearen eskuliburua
• Note: SIM card is not included.

Konfigurazio Gida

Follow these steps to set up your wendeekun 4G LTE Modem Dongle and establish an internet connection.

1. SIM txartelaren instalazioa

1. Prepare a Micro SIM card (not included).
2. Gently open the back cover of the modem dongle.
3. Insert the Micro SIM card into the designated slot, ensuring correct orientation.
4. Itxi atzeko estalkia ongi.

2. Connecting the Dongle

1. Insert the modem dongle into a computer's USB port or any other compatible USB power supply port.
2. The LED status indicator will illuminate, indicating the device is powered on.

3. Sarera konektatzea

Once the dongle is connected, you can connect your devices to its Wi-Fi network.

For Windows (7/8/10/Vista):

1. Ireki Kontrol panela > Sarea eta Internet > Sare eta Partekatzeko Zentroa.
2. Hautatu Konektatu sarera.
3. In the list of available networks, select the Wi-Fi network with the SSID: 4G MIFI**** (edo 4GUFI_**** for UFI models).
4. Enter the Default Password: 1234567890 eta sakatu Ados.
5. Wait for the connection status to show "Connected".

Android telefonoetarako:

1. Joan zaitez Ezarpenak.
2. Sakatu Wi-Fi switch to turn on Wi-Fi.
3. In the list, select the network that matches the device's SSID (e.g., 4G MIFI****).
4. Enter the correct password (1234567890) and tap Konektatu.

Oharra: The SSID and default password are typically printed on the device or included in the packaging.

Funtzionamendu-argibideak

Once connected, your modem dongle functions as a portable Wi-Fi hotspot.

Sare partekatzea

The dongle allows up to 10 associated users to connect simultaneously to its Wi-Fi network, sharing the 4G LTE internet connection.

4. irudia: Visual representation of using the modem dongle for 4G internet access via a SIM card, increasing Wi-Fi coverage and eliminating network dead spots.

LED egoera adierazlea

The LED indicator provides visual cues about the device's operational status. Refer to the device's specific LED patterns for detailed status information (e.g., connected, searching for network, no SIM).

Memory Card Expansion

The modem dongle supports the expansion of storage via a small memory card (up to 32GB, not included). This feature allows for additional data storage directly on the device.

Mantentzea

To ensure the longevity and optimal performance of your modem dongle, follow these general maintenance guidelines:

• Mantendu gailua garbi eta hautsik gabe. Erabili zapi leun eta lehor bat garbitzeko.
• Saihestu gailua muturreko tenperatura, eguzki-argi zuzena edo hezetasun handiaren eraginpean jartzea.
• Ez erori edo ez jarri gailua kolpe handirik.
• Gorde gailua leku fresko eta lehor batean erabiltzen ez duzunean.
• Ensure the USB port and SIM card slot are free from debris.

Arazoak konpontzea

If you encounter issues with your modem dongle, refer to the following common troubleshooting steps:

No Internet Connection After Reconnecting

If the product is unplugged and then plugged back into the same USB port, you may need to re-initiate the connection:

• Click the installed software or connection utility again to re-establish the connection.

Device Not Recognized / No Power

• Ensure the dongle is fully inserted into the USB port.
• Try a different USB port on your computer or a different USB power adapter.
• Verify that the USB port is functional.

Ezin da Wi-Fi sarera konektatu

• Double-check the Wi-Fi SSID and password. Ensure you are entering the default password 1234567890 unless you have changed it.
• Ziurtatu SIM txartela behar bezala sartuta dagoela eta datu-plan batekin aktibo dagoela.
• Restart the modem dongle by unplugging and re-plugging it.
• Check if the LED status indicator shows any error states.

Interneteko abiadura motela

• Ensure you are within good signal range of your cellular network.
• Reduce the number of connected devices if multiple users are sharing the connection.
• Check your SIM card's data plan for any speed limitations or data caps.

Zehaztapenak

Bezeroarentzako Arreta

wendeekun is committed to providing quality service and support for its products. If you have any questions, encounter issues, or require assistance with your 4G LTE Modem Dongle, please contact our professional customer service team.

• 24-Hour Online Support: Our team is available to assist you with any product-related inquiries.
• For contact information, please refer to the product packaging or the official wendeekun webgunea.
