1. Sarrera
This manual provides essential information for the safe and efficient operation, installation, and maintenance of your Carrier 1.5 Ton 5 Star AI Flexicool Inverter Split AC. Please read this manual thoroughly before using the appliance and keep it for future reference.
The Carrier AI Flexicool Inverter Split AC is designed to provide optimal cooling performance with advanced features such as 6-in-1 Convertible Cooling, Dual Filtration, Auto Cleanser, and Stabilizer Free Operation. It is suitable for mid-sized rooms ranging from 111 sq ft to 150 sq ft.
2. Segurtasun informazioa
- Installation must be performed by qualified and authorized personnel only. Improper installation can lead to electric shock, fire, or injury.
- Ziurtatu elikadura hornidura boltage matches the specifications of the air conditioner.
- Ez sartu hatzak edo objektuak airearen sarreran/irteeran.
- Do not attempt to repair or modify the unit yourself. Contact authorized service personnel for any repairs.
- Keep the area around the outdoor unit clear to ensure proper airflow.
- If any abnormal operation (e.g., burning smell, unusual noise) occurs, immediately turn off the unit and disconnect the power supply.
3. Produktua amaitu daview eta Ezaugarri nagusiak
The Carrier AI Flexicool Inverter Split AC combines innovative technology with user-friendly design to deliver efficient and comfortable cooling.
3.1. irudia: Aurrealdea view of the Carrier 1.5 Ton 5 Star AI Flexicool Inverter Split AC indoor unit.
Figure 3.2: Key features of the Carrier AI Flexicool Inverter Split AC.
- Flexicool Inverter Technology: Variable speed compressor adjusts power based on heat load, offering Convertible 6-in-1 cooling modes to increase or decrease capacity and save up to 50% energy.
- 5 izarreko balorazio energetikoa: High efficiency with an Annual Energy Consumption of 754.05 units and an ISEER Value of 5.13.
- 100% Copper Condenser Coil with Aqua Clear Protection: Prevents rust and corrosion, ensuring better cooling and low maintenance.
- Dual Filtration: Features HD & PM 2.5 filters for improved indoor air quality.
- Insta Cool: Provides faster cooling for quick comfort.
- Hydro Blue Coating: Enhances durability and protects against corrosion.
- Refrigerant Leakage Detector: Alerts users to potential refrigerant leaks for safety.
- Auto Cleanser: Automatically disinfects and cleanses the indoor unit.
- ADC Sensor: Advanced sensors for optimal performance.
- Egonkortzailerik gabeko funtzionamendua: Operates efficiently within a 135V-280V range, eliminating the need for an external stabilizer.
- R32 Hozgarria: Environmentally friendly refrigerant with no ozone depletion potential.
- Zarata maila baxua: Operates at a quiet 38 Decibels for undisturbed comfort.
4. Instalazioa
Proper installation is crucial for the optimal performance and longevity of your air conditioner. It is recommended that installation be carried out by a certified technician.
4.1 Produktuaren neurriak
- Barne Unitatea (IDU): 94.0 cm (W) x 27.5 cm (H) x 20.5 cm (L)
- Kanpoko Unitatea (ODU): 79.0 cm (W) x 54.0 cm (H) x 28.0 cm (L)
Figure 4.1: Indoor Unit Dimensions.
Figure 4.2: Outdoor Unit Dimensions.
4.2 Zer dago kutxan
- 1 x Barruko Unitatea
- 1 x Kanpoko Unitatea
- 1 x Urruneko kontrola
- 1 x Erabiltzailearen eskuliburua
- 1 x Berme Txartela
- 1 set x Copper Installation Pipe (3 meters)
- 1 x Interconnecting Wire
5. Funtzionamendu-argibideak
Familiarize yourself with the remote control and various operating modes to maximize your comfort and energy savings.
5.1 Flexicool 6-in-1 Cooling
The 6-in-1 Flexicool technology allows you to adjust the cooling capacity to suit your needs, from 0.8 Ton (Comfy Pleasant) to 1.7 Ton (Extreme Hot), optimizing energy consumption.
Figure 5.1: Remote control and Flexicool 6-in-1 cooling options.
5.2 Insta Cool Mode
Activate Insta Cool mode for rapid cooling when you need to quickly lower the room temperature.
Figure 5.2: Insta Cool feature for faster cooling.
5.3 Stabilizer Free Operation
The AC is designed to operate reliably within a wide voltage range (135V-280V), eliminating the need for an external voltage stabilizer and maintaining home aesthetics.
Figure 5.3: Stabilizer Free Operation.
5.4 Other Operating Modes and Features
- Ezkutuko pantaila: The temperature display is discreetly integrated into the unit.
- Modu lehorra: Gelako hezetasuna murrizten du.
- Modu automatikoa: Automatikoki hautatzen du funtzionamendu modu optimoa giro-tenperaturaren arabera.
- Jarrai nazazu funtzioa: The remote control acts as a thermostat, sensing the temperature around you for personalized comfort.
- Piztu/Itzali automatikoko tenporizadorea: Set specific times for the AC to turn on or off.
- Lo egiteko modua: Energia aurrezten duen bitartean, eroso lo egiteko tenperatura eta haizagailuaren abiadura doitzen ditu.
6. Mantentzea
Mantentze-lan erregularrak zure aire girotuaren eraginkortasuna eta iraupena bermatzen ditu.
6.1 Dual Filtration System
The AC is equipped with HD and PM 2.5 filters to protect against indoor air pollution. Regularly clean or replace these filters as per the instructions in the detailed manual to maintain air quality.
Figure 6.1: Dual Filtration with HD and PM 2.5 filters.
6.2 Auto Cleanser Function
The Auto Cleanser feature automatically disinfects and cleanses the indoor unit, promoting fresher and cleaner air. Activate this function periodically.
Figure 6.2: Auto Cleanser for fresh air.
6.3 Hydro Blue Coating and Aqua Clear Protection
The Hydro Blue Coating on the indoor unit and Aqua Clear Protection on the outdoor unit's copper coils protect against corrosion and rust, ensuring long-term durability and lower maintenance costs. These coatings help maintain the efficiency of the heat exchangers.
Figure 6.3: Hydro Blue Coating for durability.
Figure 6.4: Aqua Clear Protection for outdoor unit.
7. Arazoak
This section provides solutions for common issues you might encounter. For more complex problems, please contact customer support.
- AC not cooling: Check if the temperature setting is too high, filters are clean, or doors/windows are open.
- Ezohiko zarata: Ensure the unit is installed correctly and there are no obstructions.
- Barneko unitatetik ur-ihesa: This could be due to a clogged drain pipe or improper installation. Contact service.
- Refrigerant Leakage Detector: The unit is equipped with a detector to identify refrigerant leaks, which will trigger an alert. If an alert occurs, contact service immediately.
- Berrabiarazte automatikoa: Potentzia bat izanez gerotage, the AC will automatically resume operation with previous settings once power is restored.
7.1 Integrated Sensors
The AC features multiple sensors (Ambient, Evaporator, Condenser Out, Discharge) to ensure maximum safety and continuous cooling performance by monitoring various parameters.
Figure 7.1: IDU & ODU Sensors for safety and performance.
8. Zehaztapenak
| Ezaugarri | Deskribapena |
|---|---|
| Marka | Garraiolari |
| Eredua | CAI18ES5R33F0 |
| Edukiera | 1.5 tona |
| Energia Eraginkortasuna | 5 izar |
| Urteko Energia Kontsumoa | 754.05 kilowatt-ordu urtean |
| ISEER Balioa | 5.13 |
| Zarata Maila | 38 dezibelio |
| Instalazio mota | Zatiketa Sistema |
| Gas hozgarria | R32 |
| Kondentsadorearen bobina | %100 kobrea |
| liburukiatage | 230 voltio (AC) |
| Wattage | 1260 Watt |
| Kolorea | Zuria |
| Materiala | ABS plastikoa |
9. Bermea eta Laguntza
Your Carrier AI Flexicool Inverter Split AC comes with comprehensive warranty coverage:
- 10 urteko bermea on Compressor
- 5 urteko bermea on PCB (Printed Circuit Board)
- 1 Urteko Bermea on the Product
Figure 9.1: Warranty details for Carrier AC components.
For any service requests, technical assistance, or warranty claims, please contact Carrier Customer Care:
- Bezeroarentzako arreta: 18001033333
- Fabrikatzailea: Carrier Midea India Private Limited, 1st Floor, Pearl Tower, Plot no. 51, Sector-32, Gurgaon-122001
