Sarrera
The Cisco Headset 721 is a wireless on-ear Bluetooth headset designed for professional use, offering comfort and advanced features for communication and collaboration. This manual provides comprehensive instructions for its setup, operation, and maintenance.
Kutxan dagoena
Egiaztatu elementu guztiak paketean daudela:
- Cisco Headset 721 (Single On-Ear Headset)
- USB-A HD Bluetooth Adapter
- Kargatzeko euskarria
- USB-A kargatzeko kablea
- Babes-zorro biguna
- Belarri-kuxinak (aurrez instalatuta edo ordezkoak)
- Buruko zinta (integratua)
Image: The Cisco Headset 721 shown alongside its soft protective case, highlighting its portability.
Konfigurazioa
1. Entzungailua kargatzea
Before initial use, fully charge the headset. The headset has a battery life of approximately 23 hours of talk time.
- Connect the USB-A charging cable to the charging stand.
- Connect the other end of the USB-A charging cable to a powered USB port (e.g., computer, wall adapter).
- Place the headset onto the charging stand, ensuring proper alignment. The LED indicator on the headset will show charging status.
2. Bluetooth bidez konektatzen
The headset can connect wirelessly to two devices simultaneously via Bluetooth.
- Piztu: Press and hold the Power button on the headset until the LED indicator flashes.
- Parekatze modua: With the headset powered on, press and hold the Bluetooth button until the LED indicator flashes blue and red alternately. This indicates pairing mode.
- Gailuaren parekatzea: On your device (e.g., smartphone, laptop), go to Bluetooth settings and select "Cisco Headset 721" from the list of available devices.
- Berrespena: The headset LED will turn solid blue when successfully paired.
3. Connecting with USB-A HD Bluetooth Adapter
For optimal performance and integration with Cisco applications, use the provided USB-A HD Bluetooth Adapter.
- Plug the USB-A HD Bluetooth Adapter into an available USB-A port on your computer.
- The adapter will automatically attempt to pair with your Cisco Headset 721. The LED on the adapter will indicate connection status.
- Ensure your headset is in pairing mode if it does not connect automatically.
Image: The Cisco Headset 721, USB-A adapter, and charging stand arranged on a desk, illustrating a typical setup.
4. Adjusting the Microphone Boom Arm
The microphone boom arm rotates 276 degrees for optimal placement and features a flip-to-mute function.
- Position the microphone approximately two finger-widths from the corner of your mouth for clear audio.
- To mute the microphone, flip the boom arm upwards. Flip it down to unmute.
Funtzionamendu-argibideak
Belarrietako kontrolak
The headset features intuitive on-ear controls for managing calls and media.
- Bolumena igo/behera: Erabili bolumen-botoi dedikatuak audio-mailak doitzeko.
- Deia erantzun/amaitu: Press the Call button once to answer an incoming call or end an active call.
- Ezkutatu/Aktibatu: In addition to the flip-to-mute boom arm, a dedicated mute button may be present for quick toggling.
- Erreproduzitu/Pausatu multimedia: Press the Call button once to play or pause media playback.
- Hurrengoa / Aurreko pista: Use specific media control buttons if available, or double-press/triple-press the Call button (refer to specific model documentation for exact functionality).
Webex Button Integration
Dedikatua. Webex button provides seamless integration with Cisco Webex applications.
- Sartu Webohia bilera: Sakatu Webex button to quickly join an active or scheduled Webbilera ohia.
- Webex Control: The button may also provide quick access to other Webex-specific functions depending on the application version.
Image: A person wearing the Cisco Headset 721 while engaged in a video conference on a large display, demonstrating its use in a professional setting.
AI Voice-Activated Microphones
The headset features AI voice-activated microphones designed to minimize background noise, ensuring clear communication.
- These microphones automatically focus on your voice and suppress ambient sounds.
- No specific user action is required for this feature; it operates automatically.
Puntu anitzeko bikotea
The headset supports multipoint pairing, allowing it to be connected to two Bluetooth devices simultaneously.
- Once paired with two devices, the headset can seamlessly switch between them for calls or media.
- Adibidezample, you can be connected to your laptop for a video conference and your smartphone for incoming calls.
Mantentzea
Aurikularra garbitzea
Regular cleaning helps maintain the headset's hygiene and performance.
- Erabili zapi leun, lehor eta lihorik gabeko bat entzungailuen gainazalak garbitzeko.
- Belarri-kuxinetarako, garbitu astiro-astiro zapi batekin.amp cloth (water only) and allow to air dry completely before use.
- Saihestu produktu kimiko gogorrak, disolbatzaileak edo material urratzaileak erabiltzea.
Biltegiratzea
When not in use, store the headset properly to protect it from damage.
- Use the provided soft protective case for storage and transport.
- Gorde leku fresko eta lehor batean, eguzki-argitik eta muturreko tenperaturatik urrun.
Arazoak konpontzea
Ohiko arazoak eta irtenbideak
| Gaia | Irtenbidea |
|---|---|
| Aurikularrak ez dira pizten. | Ensure the headset is fully charged. Connect it to the charging stand and check the LED indicator. |
| Ezin da gailu batekin parekatu. | Ensure the headset is in pairing mode (LED flashing blue/red). Check your device's Bluetooth settings. Try restarting both the headset and the device. |
| Ez dago audiorik edo audioaren kalitate eskasa. | Check the volume levels on both the headset and the connected device. Ensure the headset is selected as the audio output device. Move closer to the connected device to avoid interference. |
| Mikrofonoa ez dabil. | Ensure the microphone boom arm is flipped down (unmuted). Check microphone settings on your connected device/application (e.g., Webadib.). |
| Webex button not responding. | Ensure the headset is properly connected to a device running the Webex application. Verify that the Webex application is up to date. |
Zehaztapenak
| Ezaugarri | Xehetasuna |
|---|---|
| Modelo zenbakia | HS-WL-721-BUNAS-C |
| Konektibitate Teknologia | Haririk gabeko (Bluetooth) |
| Bluetooth bertsioa | 4.0 |
| Bluetooth barrutia | 10 metro |
| Belarrien Kokatzea | Belarrian |
| Forma-faktorea | Belarrian |
| Zarata Kontrola | Passive Noise Cancellation, Sound Isolation |
| Bateriaren iraupena | 23 ordu (elkarrizketa denbora) |
| Kontrol mota | Call Control, Button, App |
| Ezaugarri bereziak | Adjustable Headband, Fast Charging, Lightweight, Multipoint Pairing, Noise Isolation |
| Gailu bateragarriak | Telefono mugikorrak, mahaigaineko ordenagailuak, ordenagailu eramangarriak, tabletak |
| Elementuaren pisua | 0.12 kilogramo (4.2 ontza) |
| Materiala | Aluminum, Stainless Steel, Leather or Faux Leather, Memory Foam |
| Dakarten osagaiak | Cable, Charging Station, Ear Cushions, Headband, Protective Case |
Bermea eta Laguntza
The Cisco Headset 721 comes with a Two-Year Limited Liability Warranty, ensuring peace of mind regarding manufacturing defects and performance issues.
For technical support, warranty claims, or further assistance, please visit the official Cisco support website or contact your Cisco product provider. Ensure you have your product model number (HS-WL-721-BUNAS-C) and proof of purchase available.
Aukerako Babes Planak
Additional protection plans may be available for extended coverage:
- 2 Urteko Babes Plana: Extends coverage for 24 months.
- 3 Urteko Babes Plana: Extends coverage for 36 months.
- Babes osoa: Iraganeko eta etorkizuneko erosketak barne hartzen dituen hileko plana.
Please refer to the terms and conditions of these plans for full details.
