Darlee Santa Barbara 7 Piece Cast Aluminum Patio Fire Pit Dining Set User Manual

Sarrera

This manual provides essential information for the safe assembly, operation, and maintenance of your Darlee Santa Barbara 7 Piece Cast Aluminum Patio Fire Pit Dining Set. Please read all instructions carefully before assembly and use to ensure proper function and longevity of your product.

Segurtasun Informazioa

Beti jarraitu oinarrizko segurtasun neurriak produktu hau erabiltzean, sute, deskarga elektriko edo pertsonen lesio arriskua murrizteko.

• Keep children and pets away from the fire pit area.
• Do not use the fire pit in an enclosed space. Ensure adequate ventilation.
• Ensure the fire pit is on a level, non-combustible surface.
• Ez biltegiratu edo erabili gasolina edo bestelako lurrun eta likido sukoiak aparatu honen edo beste edozein aparaturen inguruan.
• Always turn off the gas supply when the fire pit is not in use.
• Utzi su-hobia guztiz hozten mugitu edo estali aurretik.

Paketearen edukia

Muntaketa hasi aurretik, egiaztatu osagai guztiak daudela.

• 1 x 60-inch Round Fire Pit Dining Table
• 6 x Dining Arm Chairs
• 6 x Sesame Polyester Cushions
• 1 x Lid for Fire Pit Burner
• 1 x Bag of Ocean Blue Fire Glass
• Hardware Pack (bolts, washers, nuts, wrench)

Image: The complete Darlee Santa Barbara 7 Piece Cast Aluminum Patio Fire Pit Dining Set, showing the round fire pit table and six dining armchairs with cushions, set up in an outdoor patio area.

Konfigurazioa eta Muntaketa

Assembly requires two adults and approximately 1-2 hours. Do not overtighten bolts until all components are loosely assembled.

Beharrezko tresnak:

• Adjustable Wrench (provided)
• Phillips buruko bihurkina (ez da ematen)

Muntatzeko urratsak:

1. Step 1: Assemble Dining Chairs

   Attach the chair back to the seat frame using the provided bolts and washers. Then, attach the front legs to the seat frame. Ensure all connections are secure but do not fully tighten yet.



   Irudia: Gertutik view of the Darlee Santa Barbara dining armchair, showcasing its intricate cast aluminum backrest design and sturdy frame, without the cushion.

   Once all parts are aligned, fully tighten all bolts. Repeat for all six chairs.

2. Step 2: Assemble Fire Pit Dining Table Base

   Connect the side panels of the fire pit table base. Ensure the propane tank access door is correctly oriented.
3. Step 3: Attach Tabletop to Base

   Carefully place the 60-inch round tabletop onto the assembled base. Align the pre-drilled holes and secure with bolts. Ensure the fire pit burner opening is centered.



   Irudia: Xehetasun zehatza view of the Darlee Santa Barbara 60-inch round fire pit dining table with the fire lit, showing the intricate tabletop design and the central fire pit with blue fire glass.

4. Step 4: Install Fire Pit Components

   Place the burner pan into the tabletop opening. Connect the gas hose from the burner to the propane tank regulator. Distribute the Ocean Blue fire glass evenly over the burner pan.



   Irudia: Goiko planoa view of the Darlee Santa Barbara 60-inch round fire pit dining table, highlighting the detailed woven pattern of the cast aluminum tabletop and the central fire pit area.

5. 5. urratsa: Jarri kuxinak

   Place the sesame polyester cushions onto the assembled dining chairs.



   Irudia: Gertutik view of the Darlee Santa Barbara dining armchair with a sesame polyester cushion placed on the seat, showing the comfort and design of the chair.

Operating Instructions (Fire Pit)

Propano depositua konektatzea:

1. Ensure the fire pit control knob is in the "OFF" position.
2. Place a standard 20 lb. propane tank (not included) into the designated compartment within the table base.
3. Connect the regulator hose from the fire pit to the propane tank valve. Hand-tighten firmly.
4. Check for gas leaks using a soapy water solution on all connections. Bubbles indicate a leak. Do not operate if a leak is detected.

Su-zuloa piztea:

1. Ireki propano-tanga balbula poliki-poliki.
2. Push and turn the control knob to the "LOW" position.
3. Press the igniter button repeatedly until the burner ignites.
4. Once lit, continue to hold the control knob for 15-20 seconds to allow the thermocouple to heat up.
5. Release the knob. If the flame extinguishes, repeat the lighting procedure.
6. Doitu sugarraren altuera kontrol-botoia "BAXU" eta "ALTU" artean biratuz.

Sua itzaltzea:

1. Biratu kontrol-botoia "OFF" posiziora.
2. Itxi propano deposituaren balbula.
3. Utzi su-hobia guztiz hozten estali edo gorde aurretik.

Mantentzea eta zaintzea

Mantentze egokiak zure patioko multzoaren bizitza eta itxura luzatuko ditu.

• Markoak garbitzea: Wipe with a dry cloth as per manufacturer's instructions. For deeper cleaning, use a mild soap and water solution. Rinse thoroughly and dry immediately to prevent water spots. Avoid harsh chemicals or abrasive cleaners.
• Kuxinen zainketa: The sesame polyester cushions are moisture resistant. Clean spills immediately with a damp cloth. For deeper cleaning, use a mild soap solution and air dry. Store cushions indoors during inclement weather or prolonged periods of non-use to prevent fading and mildew.
• Fire Pit Care: Keep the burner area clean and free of debris. Use the provided lid to protect the burner when the fire pit is not in use. Periodically check gas connections for leaks.
• Neguko biltegiratzea: During winter months or extended periods of non-use, it is recommended to cover the entire set with a weather-resistant cover or store it in a dry, protected area to preserve its finish and components.

Arazoak konpontzea

Zehaztapenak

• Eredua: 201010-7PC-60GD
• Marka: Mailegua
• Materiala: Cast Aluminum Frame, Polyester Cushions
• Amaiera: Antique Bronze (Powder-Coated)
• Taularen neurriak: 60 hazbete (Z) x 60 hazbete (S) x 29 hazbete (A)
• Aulkiaren neurriak: 24 hazbete (Z) x 25 hazbete (S) x 36.5 hazbete (A)
• Eserlekuaren altuera: 16.5 hazbetekoa
• Besoaren altuera: 25.5 hazbetekoa
• Erregai mota: Propane (Standard 20 lb. tank)
• Barne: Fire Pit Dining Table, 6 Dining Arm Chairs, 6 Sesame Cushions, Ocean Blue Fire Glass, Burner Lid.
• Produktuen zainketa: Garbitu zapi lehorrekin

Bermearen informazioa

Darlee products are manufactured with high-quality materials and craftsmanship. For specific warranty details regarding your Santa Barbara Patio Fire Pit Dining Set, please refer to the warranty card included with your purchase or visit the official Darlee webgunea. Gorde erosketaren egiaztagiria berme-erreklamazioetarako.

Bezeroarentzako Arreta

If you have any questions, require assistance with assembly, or need to report missing/damaged parts, please contact Darlee customer support. Please have your model number (201010-7PC-60GD) and purchase information ready when contacting support.

Laguntza gehiago behar baduzu, bisitatu Darlee Brand Store on Amazon edo kontsultatu zure produktuaren ontzian emandako harremanetarako informazioa.
