ZunDian Portable Car Battery Booster Jump Starter (Model 020) Instruction Manual

1. Produktua amaitu daview

The ZunDian Portable Car Battery Booster Jump Starter (Model 020) is a robust and versatile device designed to provide reliable power for various automotive and electronic needs. With a peak current of 3000A, it can quickly revive low voltage and completely drained car batteries, suitable for engines up to 6.0L gas and 3.0L diesel. Beyond jump-starting, it functions as a portable power bank and features an emergency flashlight.

Ezaugarri nagusiak:

• Powerful Jump Starter: 3000A peak current for 12V vehicles, capable of starting up to 6.0L gas and 3.0L diesel engines.
• Versatile Power Bank: Equipped with a Type-C in/out port and a Quick Charge 3.0 USB port for charging electronic devices like phones and tablets.
• Larrialdiko LED argia: Integrated flashlight with multiple modes (lighting, SOS, strobe) for visibility in dark situations.
• Segurtasun Babesak: Designed with multiple safety features to ensure secure operation.
• Diseinu eramangarria: Compact and easy to store, making it an essential emergency tool for any vehicle.

2. Paketearen edukia

Ziurtatu elementu guztiak daudela kutxa irekitzean:

• ZunDian Portable Car Battery Booster Jump Starter (Model 020)
• Smart Jumper Cables with Clamps (Gorria positiborako, Beltza negatiborako)
• USB kargatzeko kablea (C motakoa)
• Hormako kargagailu egokitzailea
• Erabiltzailearen eskuliburua
• Biltegiratze-zorroa

Image: ZunDian Jump Starter kit contents, including the main unit, smart jumper cables, charging cables, and user manual, neatly organized in a compact carrying case.

3. Konfigurazioa eta kargatzea

Hasierako karga:

1. Before first use, fully charge the jump starter.
2. Connect the provided USB charging cable to the Type-C input port on the jump starter.
3. Plug the other end of the USB cable into the wall charger adapter and then into a power outlet.
4. The LCD screen will display the charging progress. Charge until it shows 100%.

Bateriaren maila egiaztatzea:

Press the power button on the jump starter. The LCD screen will display the current battery percentage. It is recommended to keep the device charged above 50% for optimal performance.

Image: The ZunDian Jump Starter unit showing its LCD display at 100% charge, highlighting its USB-A and USB-C output ports for charging external devices.

4. Funtzionamendu-argibideak

4.1. Ibilgailu bat abiaraztean:

1. Ensure the jump starter is sufficiently charged (preferably above 50%).
2. Connect the smart jumper cables to the jump starter's dedicated port. Ensure a secure connection.
3. Lotu kable gorria (positiboa)amp ibilgailuaren bateriaren terminal positibora (+).
4. Erantsi cl beltza (negatiboa)amp ibilgailuaren bateriaren terminal negatibora (-).
5. Once connected, the indicator light on the smart jumper cables should turn green, indicating a safe connection. If it's red, check connections for polarity or shorts.
6. Start your vehicle. If it doesn't start immediately, wait 30 seconds and try again. Do not crank for more than 3 seconds per attempt.
7. Once the vehicle starts, immediately remove the jumper cables from the vehicle battery, then disconnect them from the jump starter.

Image: Demonstrates the connection process of the ZunDian Jump Starter to a car battery. The unit shows a full charge, and the smart cables indicate readiness with a green light.

4.2. Using as a Power Bank:

The jump starter can charge various electronic devices:

• Connect your device's USB charging cable to either the Type-C or Quick Charge 3.0 USB output port on the jump starter.
• Abiarazleak automatikoki hasiko da zure gailua kargatzen.

4.3. Emergency LED Light:

The integrated LED flashlight offers multiple modes:

1. Press and hold the power button for a few seconds to turn on the flashlight (steady light mode).
2. Press the power button again to cycle through modes: steady light → SOS signal → strobe light.
3. Sakatu eta eutsi berriro pizteko botoia linterna itzaltzeko.

Image: The ZunDian Jump Starter's emergency LED light in use, providing illumination for working on a car engine in low-light conditions. The image also depicts SOS and strobe light icons.

5. Segurtasun Babesak

The ZunDian Jump Starter (Model 020) incorporates 10 safety protections to ensure user safety and prevent damage to the device and vehicle. These include:

• Zirkuitu laburren babesa
• Gehiegizko korrontearen babesa
• Gehiegizko karga babesa
• Deskarga gehiegizko babesa
• Tenperatura gehiegizko babesa
• Alderantzizko polaritate babesa
• Alderantzizko konexioaren babesa
• Bolumen baxuatage babesa
• Bolumen altuatage babesa
• Spark-proof technology

Image: The smart jumper cables connected to the ZunDian Jump Starter, showing a green light that indicates the active 10 safety protections when connected to a car battery.

6. Mantentzea eta biltegiratzea

• Kargatzen: Recharge the jump starter every 3-6 months, even if not used, to maintain battery health.
• Garbiketa: Erabili zapi leun eta lehor bat gailua garbitzeko. Ez erabili produktu kimiko gogorrik edo material urratzailerik.
• Biltegiratzea: Store the jump starter in its provided carrying case in a cool, dry place, away from direct sunlight and extreme temperatures.
• Tenperatura: Avoid operating or storing the device in temperatures below -4°F (-20°C) or above 140°F (60°C).

7. Arazoak

• Ibilgailua ez da martxan jartzen:
  • Check if the jump starter is sufficiently charged.
  • Ziurtatu jauzi-kablea clampBateriaren terminal egokietara ondo konektatuta daude (gorria positibora, beltza negatibora).
  • Verify the smart cable indicator light is green. If red, re-check connections.
  • Wait 30 seconds between attempts if the vehicle doesn't start on the first try.
• Jump starter not charging:
  • Ensure the charging cable and adapter are properly connected to a working power outlet.
  • Try a different charging cable or adapter if available.
• Gailua ez da pizten:
  • Ensure the device has sufficient charge.
  • Sakatu eta eutsi pizteko botoia segundo batzuetan, sakatze azkar bat ez dela ziurtatzeko.

8. Produktuaren zehaztapenak

9. Bermea eta Laguntza

For warranty information and customer support, please refer to the documentation included in your package or visit the official ZunDian webgunea. Gorde erosketa-agiria berme-erreklamazioetarako.
