1. Segurtasun informazio garrantzitsua
Please read all safety instructions carefully before using your Xiaomi TV S Mini LED 75" 2025. Keep this manual for future reference.
- Energia iturria: Connect the TV only to an AC power source as indicated on the label.
- Aireztapena: Ziurtatu telebistaren inguruan aireztapen egokia dagoela. Ez blokeatu aireztapen-irekidurak.
- Ura eta hezetasuna: Ez jarri telebista euripean edo hezetasunean. Ez jarri likidoz betetako objekturik telebistaren gainean.
- Garbiketa: Deskonektatu telebista garbitu aurretik. Erabili zapi leun eta lehor bat. Saihestu garbitzaile likidoak.
- Zerbitzua: Ez saiatu produktu hau zuk zeuk ematen. Bidali zerbitzu guztiak zerbitzu kualifikatuko langileengana.
- Lekua: Jarri telebista gainazal egonkor eta lau batean edo muntatu horman modu seguruan VESA euskarri bateragarri bat erabiliz.
2. Paketearen edukia
Egiaztatu elementu guztiak paketean daudela:
- Xiaomi S Mini LED telebista 75" 2025
- Urruneko Kontrola
- Elikatze-kablea
- Telebista-euskarriaren osagaiak (barne badaude)
- Erabiltzailearen eskuliburua (dokumentu hau)
3. Konfigurazio gida
3.1 Telebista despaketatzea
Carefully remove the TV from its packaging. It is recommended to have two people for this process due to the size and weight of the 75-inch model.
3.2 Installing the TV Stand (Optional)
If you are not wall-mounting the TV, attach the included stand components according to the separate stand installation guide. Ensure all screws are tightened securely.
3.3 Horman muntatzea (aukerakoa)
The Xiaomi TV S Mini LED 75" 2025 supports VESA wall mounts with a pattern of 400 x 300 mm. Use appropriate wall-mounting hardware and consult a professional for installation to prevent injury or damage.
3.4 Periferikoak konektatzea
Connect your devices to the TV's input ports. Refer to the back panel image for port locations.
Irudia: Atzealdea view of the TV displaying available connection ports.
- Potentzia: Konektatu elikatze-kablea telebistara eta gero entxufe batera.
- HDMI: Connect Blu-ray players, game consoles, or other HDMI devices.
- USBa: Konektatu USB biltegiratze gailuak multimedia erreproduzitzeko.
- Ethernet: Interneteko kable bidezko konexio baterako.
- Antena/Kablea: Konektatu antena edo kable bidezko telebistaren sarrera.
3.5 Hasierako piztea eta lehen konfigurazioa
After connecting all cables, plug in the TV and press the power button on the remote control. Follow the on-screen instructions to complete the initial setup, including network connection, Google account login, and channel scanning.
Irudia: Aurrealdea view of the Xiaomi TV S Mini LED 75" 2025.
4. Funtzionamendu-argibideak
4.1 Urruneko kontrola baino gehiagoview
The included remote control provides access to all TV functions. Familiarize yourself with the button layout for easy navigation.
4.2 Oinarrizko funtzioak
- Potentzia: Sakatu telebista pizteko edo itzaltzeko.
- Bolumena: Use the +/- buttons to adjust the sound level.
- Kanala: Erabili CH +/- botoiak kanalak aldatzeko.
- Sarrera: Select the desired input source (HDMI, AV, etc.).
- Hasiera: Access the Google TV home screen.
4.3 Telebista adimendunaren ezaugarriak (Google TV)
Your Xiaomi TV runs on Google TV, offering a personalized entertainment experience.
Image: Google TV interface with app icons and content suggestions.
- Aplikazioak: Deskargatu eta instalatu aplikazioak Google Play Store-tik.
- Ahots laguntzailea: Use the built-in Google Assistant for voice commands.
- Edukiaren gomendioak: Google TV provides personalized recommendations based on your viewohiturak.
Image: Using the Hey Google voice assistant to search for content.
4.4 Pantailaren ezarpenak
Adjust picture settings to optimize your viewesperientzia.
Irudia: Gainetikview of the TV's advanced display technologies.
- Irudi moduak: Select from various preset modes (e.g., Standard, Vivid, Movie, Game) or customize your own.
- Distira/Kontrastea: Fine-tune these settings for optimal visual clarity. The TV features 1200 nits peak brightness for stunning visuals.
- Kolorea: Adjust color saturation and tint. The QD-MiniLED display offers accurate color reproduction.
- Freskatze-tasa: The TV supports a 144Hz refresh rate for ultra-smooth motion.
- AI Engine: The powerful AI engine enhances image quality automatically.
Image: Visual representation of the 144Hz refresh rate for seamless motion.
Image: The Quad cortex A73 processor, responsible for AI image enhancement and performance.
4.5 Audio ezarpenak
Configure audio output and sound enhancements.
Image: Depiction of the TV's quality audio-visual experience.
- Soinu modua: Choose from preset sound modes (e.g., Standard, Movie, Music) or customize.
- Dolby Atmos: Enable Dolby Atmos for an immersive audio experience.
4.6 Konektibitatea
The TV offers various connectivity options.
- Bluetootha: Connect Bluetooth-enabled devices such as headphones or speakers.
- Wi-Fi: Konektatu etxeko haririk gabeko sarera interneterako sarbidea izateko.
- Apple AirPlay: Edukia zuzenean erreproduzitu zure Apple gailuetatik.
Image: Apple AirPlay functionality for streaming from Apple devices.
5. Mantentzea
5.1 Pantaila garbitzea
To clean the screen, first unplug the TV. Gently wipe the screen with a soft, lint-free cloth. For stubborn marks, slightly dampen the cloth with water or a specialized screen cleaner, then wipe dry immediately. Do not spray liquid directly onto the screen.
5.2 Software eguneraketak
The TV may receive software updates periodically to improve performance and add new features. Ensure your TV is connected to the internet to receive these updates. You can check for updates manually in the TV's settings menu.
6. Arazoak
Telebistarekin arazoak badituzu, jo ezazu ohiko irtenbide hauetara:
| Arazoa | Irtenbide posiblea |
|---|---|
| Botererik ez | Egiaztatu kablea telebistara eta entxufearekin ondo konektatuta dagoen. Ziurtatu entxufea funtzionatzen duela. |
| Ez dago irudirik, baina soinua badago | Egiaztatu sarrera-iturri zuzena hautatuta dagoela. Egiaztatu kanpoko gailuetarako kable-konexioak. |
| Soinurik ez, baina irudia badago | Check volume level and mute status. Ensure audio cables are connected correctly. |
| Urruneko kontrola ez dabil | Replace batteries. Ensure no obstructions between the remote and the TV. |
| Irudiaren kalitate eskasa | Adjust picture settings (brightness, contrast, sharpness). Check antenna or cable connection. Ensure content source is high quality. |
| Smart TV features unresponsive | Check internet connection. Restart the TV by unplugging it for a few minutes and plugging it back in. |
If the issue persists after trying these steps, contact customer support.
7. Zehaztapenak
Key technical specifications for the Xiaomi TV S Mini LED 75" 2025:
| Ezaugarri | Zehaztapena |
|---|---|
| Marka | XIAOMI |
| Modelo zenbakia | 59292 |
| Pantailaren tamaina | 75 hazbete |
| Bistaratzeko Teknologia | 4K UHD, LED, QD-MiniLED |
| Ebazpena | 4K (3840 x 2160) |
| Freskatze tasa | 144 Hz |
| Distira gailurra | 1200 nit |
| Sistema eragilea | Google TV |
| Prozesadorea | Lau cortex A73 |
| RAM | 3 GB |
| Biltegiratzea | 32 GB |
| Audio Teknologia | Dolby Atmos |
| Konektibitatea | Bluetooth, Wi-Fi, Apple AirPlay |
| Produktuaren neurriak (euskarriarekin) | 42.5S x 166.8Z x 102.8A cm |
| Produktuaren pisua (euskarriarekin) | 31 kg |
| VESA hormako muntaia | 400 x 300 mm |
| Dakarten osagaiak | TV, remote control, power cable |
8. Bermea eta Laguntza
Your Xiaomi TV S Mini LED 75" 2025 is covered by a manufacturer's warranty. Please refer to the warranty card included in your package for specific terms and conditions. For technical support, service inquiries, or to purchase accessories, please visit the official Xiaomi webgunearekin edo jarri harremanetan haien baimendutako zerbitzu-zentroekin.
Sareko baliabideak: For additional information, FAQs, and software downloads, visit the official Xiaomi support page.
