Atlantic Vertigo Steatite Wi-Fi Waterdrop Electric Water Heater 831217 User Manual

1. Sarrera

This manual provides essential information for the safe and efficient installation, operation, and maintenance of your Atlantic Vertigo Steatite Wi-Fi Waterdrop Electric Water Heater, model 831217. Please read these instructions carefully before installation and retain this manual for future reference. This electric water heater is designed to provide hot water for domestic use, featuring Wi-Fi connectivity for enhanced control and energy efficiency.

Figure 1: Atlantic Vertigo Steatite Wi-Fi Waterdrop electric water heater mounted vertically on a kitchen wall. The sleek, rectangular unit is silver-grey and positioned above a dark countertop with light green cabinets below. To its right, a kitchen range hood and patterned backsplash are visible. A small wooden shelf with decorative items is to its left.

2. Segurtasun informazioa

OHARRA: Failure to follow these safety instructions could result in property damage, serious injury, or death.

• Instalazioa eta mantentze-lanak langile kualifikatuek bakarrik egin behar dituzte.
• Ensure the electrical supply matches the specifications on the water heater's rating plate.
• Ez jarri ur-berogailua martxan hondatuta edo gaizki funtzionatzen badu.
• Deskonektatu beti energia edozein zerbitzu edo mantentze-lan egin aurretik.
• Ur-berogailua behar bezala lurrera konektatuta egon behar da.
• Ez blokeatu presioa arintzeko balbula.
• Mantendu material sukoiak ur-berogailutik urrun.
• Tresna hau ez da gaitasun fisiko, sentsorial edo mental murriztua duten edo esperientzia eta ezagutza falta duten pertsonek (haurrak barne) erabiltzeko, baldin eta haien segurtasunaz arduratzen den pertsona batek gailuaren erabilerari buruz gainbegiratu edo jarraibiderik eman ez badu.

3. Konfigurazioa eta instalazioa

3.1 Paketatzea

Carefully remove the water heater from its packaging. Inspect for any shipping damage. Report any damage to your supplier immediately.

3.2 Kokapen-baldintzak

• Install the water heater in a frost-free area.
• Ensure the wall can support the full weight of the water heater when filled with water (approximately 50 kg + unit weight).
• Allow adequate clearance for maintenance and service.
• The unit should be installed as close as possible to the main hot water draw-off points to minimize heat loss.

3.3 Muntaketa

Mount the water heater vertically on a sturdy wall using appropriate fasteners. Refer to the included mounting template for precise hole placement. Ensure the unit is level.

3.4 Iturgintza-konexioak

• Connect the cold water inlet to the designated port (usually marked blue).
• Connect the hot water outlet to the designated port (usually marked red).
• Install a pressure relief valve (PRV) on the cold water inlet line as per local regulations.
• Ziurtatu konexio guztiak iragazgaitzak direla.

3.5 Konexio elektrikoak

• Konektatu ur-berogailua gainkorronte-babes egokia duen zirkuitu elektriko dedikatu batera.
• Bermatu lurreratzea egokia.
• Lan elektriko guztiek tokiko araudi elektrikoen arabera jokatu behar dute.

3.6 Depositua betetzea

Before powering on, open a hot water faucet in your home to allow air to escape. Then, slowly open the cold water supply valve to fill the water heater. Once water flows steadily from the hot water faucet, close the faucet. The tank is now full.

4. Funtzionamendu-argibideak

4.1 Hasierako piztea

After filling the tank, restore power to the water heater. The unit will typically perform a self-check and then begin heating water to the default temperature setting.

4.2 Tenperaturaren doikuntza

The temperature can be adjusted via the control panel on the unit or through the dedicated Wi-Fi application. Refer to the app's instructions for detailed Wi-Fi setup and control.

• Kontrol-panela: Use the up/down arrows or rotary dial (if present) to set the desired temperature.
• Wi-Fi aplikazioa: Download the Atlantic Waterdrop app from your device's app store. Follow the in-app instructions to connect your water heater to your home Wi-Fi network and control settings remotely.

4.3 Energia Aurrezteko Ezaugarriak

This model includes energy-saving features such as smart learning modes and scheduling. Utilize these features through the Wi-Fi app to optimize energy consumption and reduce operating costs.

5. Mantentzea

Regular maintenance ensures the longevity and efficient operation of your water heater. Always disconnect power before performing any maintenance.

5.1 Urteko Ikuskapena

• Presioa arintzeko balbula (PRV): Test the PRV annually by lifting the lever. Ensure water flows freely and then reseals. If it does not reseal, replace the valve.
• Anodo haga: The steatite heating element is designed for durability, but the anode rod should be inspected every 1-2 years and replaced if significantly corroded. This helps protect the tank from corrosion.
• Sedimentuen hustuketa: Periodically drain a few liters of water from the drain valve at the bottom of the tank to remove sediment buildup.

5.2 Garbiketa

Garbitu ur-berogailuaren kanpoaldea oihal leun eta lehor batekinamp oihal. Ez erabili garbitzaile edo disolbatzaile urratzailerik.

6. Arazoak

For issues not listed here, or if solutions do not resolve the problem, contact qualified service personnel.

7. Zehaztapenak

Note: While the product title mentions 50 Liters, the detailed specifications provided indicate a 65 Liter capacity. Please verify the exact capacity of your specific unit upon receipt.

8. Bermea eta Laguntza

8.1 Bermearen informazioa

This Atlantic Vertigo Steatite Wi-Fi Waterdrop Electric Water Heater, model 831217, comes with a 5 urteko bermea. Please retain your proof of purchase for warranty claims. The warranty covers manufacturing defects under normal use and service. Specific terms and conditions may apply; refer to the warranty card included with your product or contact customer support for details.

8.2 Bezeroarentzako laguntza

For technical assistance, troubleshooting, or warranty service, please contact your retailer or the manufacturer's authorized service center. Have your model number (831217) and purchase date ready when contacting support.
