Jocoevol Shoe Cabinet Storage (Model C-0602) Instruction Manual

Sarrera

This manual provides detailed instructions for the assembly, operation, and maintenance of your Jocoevol Shoe Cabinet Storage, Model C-0602. This unit is designed for organizing footwear in entryways, hallways, living rooms, or foyers, featuring three flip drawers and one top drawer. Please read these instructions carefully before assembly and use to ensure proper function and safety.

Segurtasun Informazioa

Garrantzitsua: This cabinet is equipped with an anti-tipping device to prevent accidental tipping over. It is crucial to install this device as instructed to ensure stability and safety, especially in households with children or pets. Ensure proper assembly and placement to maintain stability. Follow all provided instructions for safe installation and use.

Paketearen edukia

Muntaketa hasi aurretik, egiaztatu behean zerrendatutako osagai guztiak daudela eta kalterik gabe daudela. Piezarik falta edo kaltetuta badago, jarri harremanetan bezeroarentzako arreta-zerbitzuarekin.

• Armairu-panelak (tamaina desberdinak)
• Metalezko Hankak
• Flip Drawer Mechanisms (3 sets)
• Top Drawer Components
• Hardware Pack (screws, dowels, cam locks, handles)
• Iraulketaren aurkako gailua
• Muntatzeko Instrukzio Eskuliburua

Muntatzeko jarraibideak

The assembly process is designed to be straightforward, with clear instructions, numbered parts, and pre-drilled holes. It is recommended that 1-2 people assemble the unit, which typically takes approximately 30 minutes.

1. Prestaketa: Unpack all components and lay them out on a clean, soft surface to prevent scratches. Identify each part using the provided labels.
2. Markoaren muntaia: Connect the main side panels to the base and top panels using the designated hardware. Ensure all connections are secure.
3. Flip Drawer Mechanism Installation: Attach the flip drawer mechanisms to the interior of the cabinet. These mechanisms allow the drawers to pivot open and close smoothly.
4. Tiraderaren muntaia: Assemble the three flip drawers and the single top drawer according to the instructions. Insert the adjustable internal panels into the flip drawers.
5. Attach Drawers: Carefully insert the assembled flip drawers into their respective mechanisms. Install the top drawer into its runners.
6. Install Metal Legs: Securely attach the black metal legs to the bottom of the cabinet. These legs provide stability and protect floors.
7. Tipping aurkako gailuaren instalazioa: This is a critical safety step. Attach the L-shaped anti-tipping screw to the back of the cabinet and secure it to a wall stud using appropriate wall anchors. This prevents the cabinet from falling forward.
8. Azken egiaztapenak: Ensure all screws are tightened, and the cabinet is stable. Test the operation of all drawers.

An illustration showing the dimensions of the shoe cabinet: 23.6 inches (W) x 51.2 inches (H) x 9.5 inches (D). A detailed inset highlights the L-shaped screw mechanism for securing the cabinet to a wall, enhancing stability and preventing tipping.

Gertu bat view demonstrating the adjustable or removable panel inside a flip drawer, allowing customization for different shoe heights.

Funtzionamendu-argibideak

The Jocoevol Shoe Cabinet is designed for convenient and organized shoe storage.

• Flip Drawers: To access your shoes, gently pull the handle on each of the three flip drawers. The drawer will pivot forward and down, revealing two tiers of storage. Push the drawer back up until it clicks into place to close. This design protects shoes from dust and keeps them out of sight.
• Biltegiratze erregulagarria: Each flip drawer features an adjustable or removable internal panel. This allows you to customize the storage space to accommodate various shoe types, from flats and sneakers to mid-calf boots and heels (up to US size 10). To adjust, simply lift and reposition the panel in the desired slot or remove it entirely for larger items.
• Goiko tiradera: The small top drawer provides additional storage for smaller items such as keys, wallets, sunglasses, or socks, keeping them organized and easily accessible.
• Alboko kakoak: The cabinet includes side hooks for hanging small bags, umbrellas, or other accessories.

The Jocoevol Shoe Cabinet with all three flip drawers fully open, revealing multiple pairs of shoes neatly organized inside each compartment. The top drawer is closed, and a small hook on the side is visible.

An image illustrating the versatility of the shoe cabinet, showing icons for high heels, slippers, casual shoes, leather shoes, sneakers, and sports shoes. An inset demonstrates how the internal panel can be removed or adjusted to accommodate different shoe heights, such as high heels.

Mantentzea

Regular maintenance will help preserve the appearance and functionality of your shoe cabinet.

• Garbiketa: Garbitu armairuaren gainazalak zapi leun etaamp oihal. Saihestu akabera kaltetu dezaketen produktu kimiko gogorrak, garbitzaile urratzaileak edo leungarriak erabiltzea.
• Hautsa botatzea: Hautsak zapi lehor eta leun batekin hautseztatu maiz, pilaketak saihesteko.
• Hardwarearen egiaztapena: Aldian-aldian egiaztatu torloju eta konexio guztiak ondo estututa daudela ziurtatzeko. Beharrezkoa bada, berriro estutu egitura-osotasuna mantentzeko.
• Saihestu hezetasuna: Protect the cabinet from excessive moisture and direct sunlight to prevent warping or fading.

Arazoak konpontzea

If you encounter any issues with your Jocoevol Shoe Cabinet, refer to the following common solutions:

• Kabinetearen ezegonkortasuna: Ensure the anti-tipping device is correctly installed and securely fastened to a wall stud. Check that all assembly screws are tightened. Verify the cabinet is placed on a level surface.
• Drawers Not Opening/Closing Smoothly: Check for any obstructions inside the drawer compartments. Ensure the flip drawer mechanisms are correctly installed and not damaged. Verify that the internal panels are properly seated.
• Falta diren piezak: If you discover any missing components during assembly, please refer to the 'Package Contents' section and contact customer support for assistance.

Zehaztapenak

Bermea eta Laguntza

Jocoevol is committed to providing quality products and customer satisfaction. For any questions regarding assembly, missing parts, or product functionality, please contact Jocoevol customer support. We aim to respond to inquiries within 24 hours.

Gorde erosketa-agiria berme-erreklamazio edo laguntza-eskaerarik baduzu.
