KERUI 3K/5MP Lite 8-Channel 6-in-1 DVR Instruction Manual

Sarrera

This manual provides comprehensive instructions for the KERUI 3K/5MP Lite 8-Channel 6-in-1 Digital Video Recorder (DVR). This DVR is designed for security camera systems, offering compatibility with various camera types including Analog, XVI, AHD, TVI, CVBS, CVI, and IP cameras. Please read this manual carefully before installation and operation to ensure proper use and optimal performance of your surveillance system.

Kutxan dagoena

Egiaztatu osagai guztiak paketean daudela:

• 1 x 8-Channel DVR Unit
• 1 x 2TB Surveillance Hard Drive (Pre-installed)
• 1 x DVR elikadura hornidura
• 1 x USB sagua
• 1 x Abisu eranskailu

Image: Contents of the KERUI 8-Channel DVR box, showing the DVR unit with dimensions, a 1TB surveillance HDD, DVR power supply, USB mouse, and warning stickers.

Konfigurazioa

1. Hasierako konexioak

Before powering on the DVR, ensure all necessary connections are made.

• Konektatu kamerak: Connect your security cameras to the appropriate video input ports (BNC connectors for Analog/AHD/TVI/CVI/XVI cameras, Ethernet for IP cameras). The DVR supports up to 8 channels for local cameras and additional IP channels depending on the configuration.
• Konektatu monitorearekin: Use an HDMI or VGA cable to connect a monitor to the DVR's corresponding output port.
• Sagua konektatu: Plug the included USB mouse into one of the USB ports on the DVR.
• Sare konexioa (aukerakoa): For remote access and network features, connect an Ethernet cable from the DVR's LAN port to your router or network switch.
• Potentzia-konexioa: Connect the DVR power supply to the DC 12V input port on the DVR, then plug the power supply into an electrical outlet.

Image: Rear panel connections of the DVR, illustrating video inputs (AHD, CVI, XVI, CVBS, TVI, IP camera compatibility), HDMI output, audio input/output, VGA input, USB input, network input, and power input.

2. Hasierako piztea eta konfigurazioa

Once all connections are secure, power on the DVR. The system will boot up and display the live view on the connected monitor. Follow the on-screen prompts for initial setup, which may include setting a password, date/time, and network settings.

Funtzionamendu-argibideak

1. Video Compression (H.265+)

The DVR utilizes advanced H.265+ video compression technology. This standard significantly improves compression ratios compared to H.264, resulting in longer recording times and up to 80% storage savings. It also enhances image quality and provides a smoother viewesperientzia.

Image: Visual comparison demonstrating the efficiency of H.265+ compression, showing reduced storage space and improved bandwidth compared to H.264.

2. Smart Motion Detection and Alerts

The DVR features intelligent motion detection and human/face detection capabilities. When abnormal activity is detected, the system can automatically trigger an alarm and send real-time notifications via email or mobile app. This allows you to monitor your property's security immediately, regardless of your location.

Irudia: Gainetikview of AI Human & Face Detection, showing real-time alerts via app push and email, with remote viewing options on mobile phones and computers.

3. Remote Access and Playback

The DVR supports remote access, allowing you to view live surveillance footage and play back recorded videos from anywhere with an internet connection. This can be done through mobile phones, computers, and other devices using the dedicated application (XMEye and Icsee) or PC software (VMS).

Image: Remote access and playback feature, showing live and recorded footage accessible via the internet, even without a constant internet connection for local recording.

4. Switching DVR Mode

The DVR supports various channel configurations to accommodate different camera types and quantities. You can switch the DVR mode through the system settings to match your camera setup.

5. Disabling Hard Disk Storage Reminder

If you wish to disable the hard disk storage reminder, follow the steps shown in the video below. This can be useful in specific scenarios where continuous reminders are not desired.

Mantentzea

To ensure the longevity and optimal performance of your KERUI DVR, consider the following maintenance tips:

• Ohiko garbiketa: Keep the DVR unit free from dust and debris. Use a soft, dry cloth for cleaning. Ensure ventilation openings are not blocked.
• Firmware eguneraketak: Aldian-aldian egiaztatu fabrikatzailearen website for firmware updates. Updates can improve performance, add features, and enhance security.
• Datuen babeskopia: Aldian-aldian egin grabatutako janari garrantzitsuen babeskopiaktage to an external storage device to prevent data loss.
• Ingurumen-baldintzak: Operate the DVR within recommended temperature and humidity ranges to prevent damage.

Arazoak konpontzea

If you encounter issues with your DVR, refer to the following common troubleshooting steps:

• Bideo-irteerarik ez: Check HDMI/VGA cable connections to the monitor and DVR. Ensure the monitor is set to the correct input source.
• Kamerak ez dira bistaratzen: Verify that cameras are properly connected and powered. Check camera compatibility with the DVR's current mode (refer to 'Switching DVR Mode' section).
• Grabaketarik ez: Ensure the hard drive is correctly installed and initialized. Check recording schedules and settings.
• Urruneko sarbidearen arazoak: Verify network cable connection and router settings. Ensure the mobile app or PC software is correctly configured and the DVR has internet access.
• Sistema izoztea/erantzuterik ez: Try restarting the DVR. If the issue persists, consider performing a factory reset (note: this will erase settings).

For more complex issues, contact customer support.

Zehaztapenak

Bermea eta Laguntza

For warranty information, please refer to the product packaging or contact your retailer. For technical support, product inquiries, or further assistance, please visit the official KERUI webwebgunera edo jarri harremanetan bezeroarentzako arreta-zerbitzuarekin. Gorde erosketa-agiria berme-erreklamazioetarako.
