OUKITEL P800 Zentral elektriko eramangarria erabiltzailearen eskuliburua

1. Sarrera

Thank you for choosing the OUKITEL P800 Portable Power Station. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your device. Please read this manual thoroughly before using the product and keep it for future reference.

The OUKITEL P800 is a high-performance 800W portable power station with a 512Wh LiFePO4 battery, designed to provide reliable power for outdoor activities, camping, RV travel, and emergency backup. It features multiple output ports and flexible charging options, including AC, solar, and car charging.

2. Segurtasun-argibideak

OHARRA: Segurtasun-jarraibide hauek ez betetzeak sua, deskarga elektrikoak edo bestelako lesio edo kalteak eragin ditzake.

• Ez desmuntatu, konpondu edo aldatu unitatea.
• Do not place the unit near fire or expose it to high temperatures.
• Ez erabili edo gorde unitatea eguzki-argitan edo ingurune beroetan.
• Do not use or store the unit in a bathroom or in areas exposed to water or humidity.
• Do not drop, hit, or subject the unit to strong impacts.
• Ez sartu objektu arrotzik portuetan edo irekiduretan.
• Mantendu haurren eta maskoten eskura.
• Ziurtatu aireztapen egokia erabiltzen eta kargatzen ari den bitartean. Ez estali unitatea.
• If the unit emits smoke, odor, or unusual noise, stop using it immediately and contact customer support.
• Dispose of the unit according to local regulations. Do not dispose of it in household waste.

3. Produktua amaitu daview

3.1 Paketearen edukia

• 1 x OUKITEL P800 Portable Power Station
• 1 x AC kargatzeko kablea
• 1 x MC4-XT60 Cable (for solar panel connection)
• 1 x Erabiltzailearen eskuliburua

3.2 Unit Features and Ports

The OUKITEL P800 features a compact design with various input and output ports for versatile use.

3.2.1. irudia: Aurrealdea view of the OUKITEL P800 Portable Power Station, highlighting its robust handle, LCD display, AC output, DC 12V output, USB-A ports, and USB-C port. The unit is designed for stability and portability.

• CA irteera: 240V, 800W (1600W Peak) for household appliances.
• DC 12V Output: Car cigarette lighter socket for 12V devices.
• USB-A atakak: Smartphone-ak, tabletak eta bestelako USB bidez elikatzen diren gailuak kargatzeko.
• USB-C ataka: Kargatze azkarreko gailu bateragarrietarako.
• LED argia: Integrated light with SOS mode for emergencies.
• LCD pantaila: Shows real-time battery level, input/output power, and operating status.
• LiFePO4 bateria: 512Wh capacity for long-lasting power.

3.2.2. irudia: Ilustrazio bat. view of the internal LiFePO4 battery cells, emphasizing the 800W AC output, 512Wh capacity, and 3.6-hour endurance for various applications.

4. Konfigurazioa

4.1 Hasierako karga

Before first use, fully charge the OUKITEL P800. This ensures optimal battery performance and calibration.

1. Connect the provided AC charging cable to the power station's AC input port.
2. Entxufatu AC kargatzeko kablearen beste muturra hormako entxufe estandar batera.
3. The LCD display will indicate charging status. Charge until the battery indicator shows 100%.

The unit supports fast charging via AC, reaching full capacity in approximately 1 hour.

4.2 Connecting a Solar Panel (Optional)

To charge using solar power, connect a compatible solar panel (e.g., OUKITEL PV100) to the power station.

1. Unfold your solar panel and place it in direct sunlight.
2. Connect the MC4 connectors from the solar panel to the MC4-XT60 cable.
3. Connect the XT60 end of the cable to the DC input port on the OUKITEL P800.
4. The LCD display will show the solar input power and charging status.

4.2.1. irudia: The OUKITEL P800 demonstrating its versatile charging methods: via car (350W, 1.4 hours), solar energy (200W, 2.5 hours), and AC power (500W, 1 hour). A solar panel is shown connected to the unit in an outdoor setting.

5. Funtzionamendu-argibideak

5.1 Piztu/Itzaltzea

• To turn on: Press and hold the main power button for 3 seconds. The LCD display will light up.
• To turn off: Press and hold the main power button for 3 seconds. The LCD display will turn off.

5.2 Using AC Output

1. Ziurtatu zentrala piztuta dagoela.
2. Press the AC output button to activate the AC outlets. The AC indicator on the LCD will illuminate.
3. Plug your AC appliance into the AC outlet. Ensure the appliance's power consumption does not exceed 800W (continuous) or 1600W (peak).
4. After use, press the AC output button again to turn off the AC outlets to conserve power.

5.2.1. irudia: The OUKITEL P800 providing power to a laptop and other electronic accessories, demonstrating its capability to support various devices in a compact and efficient manner.

5.3 Using USB and DC Outputs

1. Ziurtatu zentrala piztuta dagoela.
2. Press the DC output button to activate the DC 12V, USB-A, and USB-C ports. The DC indicator on the LCD will illuminate.
3. Connect your devices to the appropriate USB or 12V DC port.
4. After use, press the DC output button again to turn off these ports.

5.3.1. irudia: The OUKITEL P800 providing power to a laptop, camera, and phone, illustrating its use for essential electronics during power outages or remote work.

5.4 LED argia erabiltzea

• To turn on the LED light: Press the LED light button once.
• To switch to SOS mode: Press the LED light button again.
• To turn off the LED light: Press the LED light button a third time.

5.5 LCD pantailaren informazioa

LCD pantailak zentral elektrikoaren egoerari buruzko informazioa denbora errealean ematen du:

• Bateria mailaren adierazlea: Gainerako bateriaren ehunekoa erakusten dutage.
• Sarrerako potentzia: Displays the current power input (e.g., from AC, solar, or car charger).
• Irteera potentzia: Shows the current power output from AC, DC, or USB ports.
• Egoera ikonoak: Indicators for AC/DC output active, fan status, and warning messages.

5.5.1. irudia: The OUKITEL P800 operating quietly (Standby Mode <30 dB) in a bedroom, illustrating its safety features including short-circuit protection, overload protection, and temperature protection. A phone is shown charging from the unit.

6. Mantentzea

6.1 Biltegiratzea

• Gorde zentral elektrikoa leku fresko eta lehor batean, eguzki-argitik eta tenperatura altuetatik babestuta.
• Epe luzerako biltegiratze baterako, kargatu unitatea % 50-80ra gutxi gorabehera 3-6 hilabetero bateriaren egoera mantentzeko.
• Avoid storing in environments with high humidity or corrosive gases.

6.2 Garbiketa

• Erabili zapi leun eta lehor bat unitatearen kanpoaldea garbitzeko.
• Ez erabili garbitzaile edo disolbatzaile urratzailerik.
• Mantendu aireztapen-irekidurak hauts eta hondakinik gabe.

6.3 Bateria zaintzea

• The OUKITEL P800 uses a durable LiFePO4 battery.
• Saihestu bateria maiz erabat deskargatzea, horrek bere iraupena murriztu baitezake.
• Charge the unit fully before extended periods of non-use.

7. Arazoak

8. Zehaztapenak

9. Bermea eta Laguntza

OUKITEL provides a limited warranty for this product. Please refer to the warranty card included in your package or visit the official OUKITEL webwebgunean bermearen baldintza zehatzak ikusteko.

Laguntza teknikoa, arazoak konpontzeko laguntza edo berme erreklamazioak jasotzeko, jarri harremanetan OUKITELen bezeroarentzako zerbitzu ofizialaren bidez. webwebgunea edo zure erosketarekin emandako harremanetarako informazioa.
